Leuze DMU218-800/LA-M12 Ultrasonic Distance Sensor
The Leuze DMU218-800/LA-M12 Ultrasonic Distance Sensor measures 80 to 800 mm using current output and compact housing M18 threaded. Manufactured by Leuze, this Leuze Ultrasonic Distance Sensor operates on 18β30 V DC, supports IO-Link switching, and uses a metal M12 connector with IP67 protection. It belongs to the DMU series and is intended for industrial automation applications.
| Brand | Leuze |
| Product Type | Ultrasonic Distance Sensors |
| Product | DMU218-800/LA-M12 |
Leuze DMU218-800/LA-M12 Ultrasonic Distance Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Dimension (Γ x L) | 18 mm x 55 mm |
| Thread size | M18 x 1 mm |
| Measurement range | 80 ... 800 mm |
| Supply voltage UB | 18 ... 30 V, DC |
| Analog output 1 | Current |
| Switching ouput 1 | Transistor, Push-pull |
| Switching principle | IO-Link / light switching (PNP)/dark switching (NPN) |
| Switching frequency | 5 Hz |
| Response time | 100 ms |
| Con 1: Function | Signal OUT Teach input Voltage supply |
| Con 1: Type of connection | Connector |
| Con 1: Thread size | M12 |
| Con 1: Type | Male |
| Con 1: Material | Metal |
| Con 1: No. of pins | 4 -pin |
| Con1: Encoding | A-coded |
| Housing material | Metal |
| Degree of protection | IP 67 |
The Leuze DMU218-800/LA-M12 Ultrasonic Distance Sensor is a compact non-contact sensing solution for industrial automation systems. This Leuze DMU218-800/LA-M12 Ultrasonic Distance Sensor supports a 80β800 mm measurement range, operates with 18β30 V DC, and provides a current-based analog output for stable signal transmission. As part of the DMU series, it is designed for consistent distance monitoring in Indian industrial environments.
The Leuze DMU218-800/LA-M12 Ultrasonic Distance Sensor is commonly used on conveyors, packaging machines, automated assembly lines, and material handling equipment. Ultrasonic sensing allows reliable object detection regardless of color, transparency, or surface texture. The push-pull transistor output and IO-Link functionality support dependable PLC integration, while the defined response time ensures predictable performance in continuous automation operations.
The Leuze DMU218-800/LA-M12 Ultrasonic Distance Sensor combines a metal housing, IP67 protection, and standardized M12 connectivity for dependable long-term use. Leuze designs the DMU series with emphasis on electrical compatibility, mechanical durability, and repeatable sensing behavior. These characteristics make the Leuze DMU218-800/LA-M12 Ultrasonic Distance Sensor suitable for demanding industrial automation applications.
