Keyence LR-WF10 Photoelectric Sensor
The Keyence LR-WF10 Photoelectric Sensor offers Detecting Distance and Min. Spot Diameter Based on Attached Fiber Head detecting distance, White LED light source, 2 m cable type type. Manufactured by Keyence under the Keyence Photoelectric Sensor category, this model belongs to the LR-W Series.
| Brand | Keyence |
| Product Type | Photoelectric Sensor |
| Model Number | LR-WF10 |
Keyence LR-WF10 Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Type | 2 m cable type |
| Detecting distance | Detecting Distance and Min. Spot Diameter Based on Attached Fiber Head |
| Min. spot diameter | Detecting Distance and Min. Spot Diameter Based on Attached Fiber Head |
| Light source | White LED |
| Timer | OFF/ON delay/OFF delay/One-shot |
| Response time | 250 µs, 1 ms, 10 ms, 100 ms, 500 ms Selectable*1*2 |
| Control output | NPN open collector/PNP open collector selectable, 30 VDC or less, 50 mA or less, remaining voltage: 2 V or less, N.O./N.C. selectable |
| Power voltage | 10 to 30 VDC, including 10% ripple (P-P), Class 2 or LPS |
| Current consumption | 50 mA or less (without load) at 24 VDC; 90 mA or less (without load) at 12 VDC*5 |
| Enclosure rating | IP65 (IEC60529)*6*7 |
| Ambient temperature | -20 to +45 °C (No freezing) |
| "Relative humidity " | 35 to 85 % RH (No condensation) |
| "Vibration resistance " | 10 to 55 Hz, Double amplitude 1.5 mm, 2 hours in each of the X, Y, and Z directions |
| "Shock resistance " | 1,000 m/s2, 6 times in each of the X, Y, and Z directions |
| Material | Case: Zinc die cast (Nickel chrome plating), Indicator cover: PPSU, Buttons: PES, Display: PMMA (scratch-resistant coating), Cable bushing: PBT, Cable: PVC, Fiber locking mount: PBT, NBR, Silicone rubber, SUS304, SUSXM7, Adapter: PBT |
| Weight | Approx. 150 g (including cable) |
Ask for the Pricing of Keyence Fibre Type Photoelectric Sensor, LR-WF10 at unbeatable prices. Detailed Specifications of LR-WF10, features 2 m cable type, Detecting Distance and Min. Spot Diameter Based on Attached Fiber Head detecting distance, White LED light source. It has selectable resonse time of 250 µs, 1 ms, 10 ms, 100 ms, 500 ms Selectable*1*2. The sensor supports NPN open collector/PNP open collector selectable, 30 VDC or less, 50 mA or less, remaining voltage: 2 V or less, N.O./N.C. selectable, and can handle up to 10 to 30 VDC, including 10% ripple (P-P), Class 2 or LPS. The Sensor is rated IP65 (IEC60529)*6*7, for environmental resistance and functions within temperatures of -20 to +45 °C (No freezing). It withsatnds vibration of 10 to 55 Hz, Double amplitude 1.5 mm, 2 hours in each of the X, Y, and Z directions. The housing is made of Case: Zinc die cast (Nickel chrome plating), Indicator cover: PPSU, Buttons: PES, Display: PMMA (scratch-resistant coating), Cable bushing: PBT, Cable: PVC, Fiber locking mount: PBT, NBR, Silicone rubber, SUS304, SUSXM7, Adapter: PBT with various protective coatings, weighing approximately Approx. 150 g (including cable). Unlock Exclusive Pricing with a Quote for your requirement of Keyence Fibre Type Photoelectric Sensor.
