Delta DVP06XA-E2 Programmable Logic Controller
The Delta DVP06XA-E2 Programmable Logic Controller (PLC) is a versatile Analog I/O Module designed for mixed-signal control in automation systems. It provides 4 analog input channels supporting 10V, 5V voltage and 20mA, 0β20mA, 4β20mA current signals with a high-resolution 14-bit (-32,000 to +32,000) conversion range. It also includes 2 analog output channels for -10V~+10V voltage or 0β20mA / 4β20mA current output with 14-bit resolution. Powered by 24VDC, it ensures stable, accurate processing for advanced machine and process control. Manufactured by Delta, part of the Delta Programmable Logic Controller family within the DVP-ES2/EX2 Series.
| Brand | Delta |
| Product Type | Programmable Logic Controller |
| Model Number | DVP06XA-E2 |
Delta DVP06XA-E2 Programmable Logic Controller - Technical Specifications
| Specification | Value |
|---|---|
| Power Supply Voltage | 24VDC (-15%~20%) |
| Resolution | Input 14-bit (-32,000 ~+32,000) / Output 14-bit (-32,000~+32,000)/(0~+32,000) |
| Analog I/O Modules | 4 analog inputs/2 analog outputs |
| Fuse capacity | ES: 2A/ 250VAC; SV: 2.5A/ 30VDC |
| Power Consumption | 2.5W |
| Voltage input/output | voltage (10V, 5V) input/ voltage(-10V~+10V) ouput |
| Current input/output | current (20 mA, 0~20 mA, 4~20 mA) input/ current (0~20 mA, 4~20 mA) output |
| Spike Voltage Durability | 1500VAC (Primary-secondary); 1500VAC (Primary-PE); 500VAC (Secondary-PE) |
| Insulation Impedance | >5 MΞ© (all I/O point-to-ground: 500VDC) |
| Noise Immunity | ESD: 8 kV Air Discharge EFT: Power Line, 2 kV Digital I/O: 1 kV Analog & Communication I/O: 1 kV RS: 26 MHz~1GHz, 10V/m |
| Earth | The diameter of grounding wire shall not be shorter than that of the power supply cable. (When many PLCs are in use at the same time, please make sure every PLC is properly grounded.) |
| Storagr Operation Temperature | Storage: -25ΒΊC ~70ΒΊC (temperature) Operation: 0ΒΊC ~55ΒΊC (temperature) |
| Storage Operation Humidity | Storage: -25ΒΊC ~70ΒΊC (temperature) Operation: 0ΒΊC ~55ΒΊC (temperature) |
| Response Time | 3 ms/ all channels |
| Input Signal Voltage | 24VDC Β±10% (5 mA) |
Delta is a leading global provider of industrial automation solutions, delivering advanced control products that combine performance, reliability, and cost efficiency. Known for its high-quality PLCs, Delta offers a range of modules designed to meet diverse automation requirements. The DVP06XA-E2 is one such product, providing exceptional analog input and output capabilities for system expansion. As part of the Delta PLC series, the Delta DVP06XA-E2 ensures seamless integration, precise data handling, and dependable operation in demanding industrial environments. Its design reflects Deltaβs dedication to innovation, durability, and accuracy in control systems, making it a trusted choice among engineers and automation professionals.
The DVP06XA-E2 is an analog input/output point extension module designed for Delta PLC systems. It features 4 channels of analog voltage (10V, 5V) or current (20 mA, 0~20 mA, 4~20 mA) input and 2 channels of analog voltage (-10V~+10V) or current (0~20 mA, 4~20 mA) output. Both input and output offer a high 14-bit resolution, ensuring precise signal processing. The module operates on 24VDC (-15%~20%) with a low power consumption of 2.5W and delivers a fast response time of 3 ms across all channels. It provides robust electrical protection with spike voltage durability of 1500VAC and insulation impedance over 5 MΞ©. With IP-rated construction standards, it ensures noise immunity and reliable performance in harsh industrial conditions. The Delta PLC DVP06XA-E2 is engineered to deliver consistent, accurate, and efficient analog control for advanced automation needs.
With its versatile analog I/O configuration and compact design, the DVP06XA-E2 is ideal for applications such as process control, machine automation, and energy management systems. It is commonly deployed in manufacturing lines, packaging systems, and monitoring setups that require high-resolution analog signal processing. The robust build and fast response make it suitable for both precision instrumentation and heavy-duty industrial control tasks. Engineers choose the DVP06XA-E2 for its seamless integration, stable performance, and proven reliability, making it a preferred Delta Input / Output Point Extension in modern automation projects.
