Delta DRP024V480W1AA 20A 480W DIN Rail Power Supply
Delta DRP024V480W1AA is a 24V 20A DIN Rail Power Supply designed for industrial automation, factory control systems, and embedded devices that require consistent DC power. Delivering 480W output, it ensures stable voltage and current for PLCs, sensors, and industrial modules. The power supply supports a wide input voltage range of 100-240Vac with frequency compatibility of 50-60Hz for uninterrupted industrial performance. It features a Green LED (DC OK) indicator for quick operational verification. Manufactured by Delta industrial automation, this model is part of Delta power supply solutions and belongs to the Delta DIN Rail CliQ Series, offering secure terminals, compact DIN rail installation, and dependable 24V DC output for various industrial systems.
| Brand | Delta |
| Product Type | SMPS |
| Product | DRP024V480W1AA |
Delta 20A 480W DIN Rail Power Supply DRP024V480W1AA Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 20A |
| Output Voltage | 24V |
| Output Voltage Adjustment Range | 22-28Vdc |
| Output Power | 480W |
| Line Regulation | < 0.5% (@ 85-264Vac input, 100% input) |
| Load Regulation | < 1.0% (@ 85-264Vac input, 0-100% input) |
| PARD | < 240mVpp |
| Start-up Time | < 1,000ms @ nominal input (100% load) |
| Hold-up Time | > 20ms @ 115Vac & 230Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 5% @ 85-264Vac input, 0-100% load (Slew Rate: 0.1A/μs, 50% duty cycle @ 5Hz to 1kHz) |
| Start-up with Capacitive Loads | 10,000µF Max |
| Rise Time | < 100ms @ nominal input (100% load) |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 85-264Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| DC Input Voltage Range | 120-375Vdc |
| Input Current | < 5.70A @ 115Vac, < 2.80A @ 230Vac |
| Efficiency at 100% load | > 85.0% @ 115Vac, > 88.0% @ 230Vac |
| Inrush Current | < 50A @ 115Vac, < 150A @ 230Vac |
| Leakage Current | < 1.25mA @ 240Vac |
| Power Dissipation | 0% load: < 6.0W @ 115Vac & < 3.5W @ 230Vac 100% load: < 40W @ 115Vac & < 35W @ 230Vac |
| Case Chassis / Cover | Aluminium |
| Indicator | Green LED (DC OK) |
| Cooling System | Convection |
| Noise Sound Pressure Level (SPL) | < 40dBA |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input: AWG 16-14 Output: AWG 12-10 |
| Unit Weight | 1.80 kg (3.97 lb) |
| Operating Temperature | -20°C to +80°C |
| Storage Temperature | -25°C to +85°C |
| Power De-rating | Vertical: > 50°C de-rate power by 2.5% / °C |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
| Shock Test (Non-Operating) | IEC 60068-2-27, 30G (300m/S²) for a duration of 18ms, 3 times per direction, 6 times in total |
| Vibration (Non-Operating) | IEC 60068-2-6, 10Hz to 150Hz @ 50m/S² (5G peak); 90 min per axis for all X, Y, Z direction |
| Operating Altitude | 0 to 2,000 Meters (6,560 ft.) |
| Pollution Degree | 2 |
| Over Voltage Category | III According to IEC/EN 62477-1 / EN 60204-1 (clearance and creepage distances) and IEC 62103 (safety part) |
| Input Terminal | 3 Pins (Rated 300V/20A) |
| Output Terminal | 4 Pins (Rated 300V/20A) |
| Power Factor at 100% load | > 0.97 @ 115Vac, > 0.95 @ 230Vac |
The Delta DRP024V480W1AA 24V 20A DIN Rail Power Supply is ideally suited for industrial control panels, automation lines, and embedded systems that demand stable 24V DC output. Its 20A rated current provides sufficient power for multiple modules, ensuring smooth operation of PLCs, sensors, and actuators simultaneously. The DIN rail design allows organized installation within control cabinets, minimizing wiring clutter and simplifying maintenance. Built to withstand continuous industrial operation, it operates effectively from -20°C to +80°C and offers storage support from -25°C to +85°C, guaranteeing long-term reliability even under harsh environmental conditions.
Reliability and safety are key attributes of this model. The secure input and output terminals maintain dependable electrical connections, while the Green LED indicator allows instant verification of operational status. Its broad input voltage tolerance protects sensitive industrial devices from power fluctuations, reducing downtime and ensuring smooth functioning of automated production lines, factory equipment, and embedded modules. This makes it ideal for both OEMs and system integrators looking for consistent industrial-grade power delivery.
For engineers, industrial operators, and automation specialists seeking a high-performance DIN Rail power supply, the Delta DRP024V480W1AA delivers 480W 24V DC output with reliable 20A current. Its robust construction, efficient power delivery, and long-term operational stability make it suitable for continuous industrial applications. IndMALL provides this model with competitive pricing, easy quotation access, and dedicated customer support, ensuring your automation and control systems remain efficient, reliable, and protected at all times.
