Delta DRP024V240W1AA 10A 240W DIN Rail Power Supply
Delta DRP024V240W1AA is a 24V 10A DIN Rail Power Supply engineered for industrial automation, machine control, and embedded devices requiring reliable DC power. Delivering 240W output, it ensures consistent voltage and current for PLCs, sensors, and low-power modules. It operates across a wide input voltage range of 100-240Vac and frequency compatibility of 50-60Hz for uninterrupted industrial performance. The unit features a Green LED (DC OK) indicator for instant operational status. Manufactured by Delta industrial automation, this model is part of Delta power supply solutions and belongs to the Delta DIN Rail CliQ Series, combining secure terminals, compact DIN rail installation, and dependable 24V DC output for industrial systems.
| Brand | Delta |
| Product Type | SMPS |
| Product | DRP024V240W1AA |
Delta 10A 240W DIN Rail Power Supply DRP024V240W1AA Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 10A |
| Output Voltage | 24V |
| Output Voltage Adjustment Range | 24-28Vdc |
| Output Power | 240W |
| Line Regulation | < 0.5% (@ 85-264Vac input, 100% load) |
| Load Regulation | < 1.0% (@ 85-264Vac input, 0-100% load) |
| PARD | < 240mVpp |
| Start-up Time | < 1,000ms @ nominal input (100% load) |
| Hold-up Time | > 20ms @ 115Vac & 230Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 5% @ 85-264Vac input, 0-100% load (Slew Rate: 0.1A/μs, 50% duty cycle @ 5Hz to 1KHz) |
| Start-up with Capacitive Loads | 10,000µF Max |
| Rise Time | < 100ms @ nominal input (100% load) |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 85-264Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| DC Input Voltage Range | 120-375Vdc |
| Input Current | < 2.90 @ 115Vac, < 1.50A @ 230Vac |
| Efficiency at 100% load | > 89.0% @ 115Vac, > 91.0% @ 230Vac |
| Inrush Current | < 40A @ 115Vac, < 100A @ 230Vac |
| Leakage Current | < 1mA @ 240Vac |
| Power Dissipation | 0% load: < 7.4W @ 115Vac, < 5.4W @ 230Vac 100% load: < 29.6W @ 115Vac, < 23.7W @ 230Vac |
| Case Chassis / Cover | Aluminium |
| Indicator | Green LED (DC OK) |
| Cooling System | Convection |
| Noise Sound Pressure Level (SPL) | < 40dBA |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input / Output: AWG 18-14 |
| Unit Weight | 1.04 kg (2.29 lb) |
| Operating Temperature | -20°C to +80°C |
| Storage Temperature | -25°C to +85°C |
| Power De-rating | Vertical: > 50°C de-rate power by 2.5% / °C, > 70°C de-rate power by 4% / °C |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
| Shock Test (Non-Operating) | IEC 60068-2-27, 30G (300m/S²) for a duration of 18ms, 3 times per direction, 18 times in total |
| Vibration (Non-Operating) | IEC 60068-2-6, 10Hz to 150Hz @ 50m/S² (5G peak); 90 min per axis for all X, Y, Z direction |
| Operating Altitude | 0 to 2,000 Meters (6,560 ft) |
| Pollution Degree | 2 |
| Over Voltage Category | III According to IEC/EN 62477-1 / EN 60204-1 (clearance and creepage distances) and IEC 62103 (safety part) |
| Input Terminal | 3 Pins (Rated 300V/20A) |
| Output Terminal | 2 Pins (Rated 300V/20A) |
| Power Factor at 100% load | > 0.96 @ 115Vac, > 0.90 @ 230Vac |
The Delta DRP024V240W1AA 24V 10A DIN Rail Power Supply is ideal for industrial control panels, automation systems, and embedded equipment requiring stable 24V DC output. Its 10A rated current provides reliable operation for multiple low-power modules simultaneously, ensuring uninterrupted functionality. The DIN rail form factor allows compact and organized installation within control cabinets, reducing wiring complexity and simplifying maintenance. Designed for continuous operation in industrial environments, it supports an operating temperature range from -20°C to +80°C and storage from -25°C to +85°C, guaranteeing durability and stable performance under harsh conditions.
Safety and reliability are key to this model. The secure input and output terminals ensure dependable electrical connections, while the Green LED indicator offers a quick visual check of operational status. Its wide input voltage tolerance protects sensitive devices such as PLCs, sensors, and communication modules from power fluctuations. This minimizes downtime and maintains smooth functioning of automated production lines, industrial machinery, and embedded control systems.
For system integrators, OEMs, and industrial operators seeking a high-quality, compact DIN Rail power solution, the Delta DRP024V240W1AA delivers a robust 240W 24V DC output with reliable 10A current. Its industrial-grade design, efficient power delivery, and long-term operational stability make it suitable for continuous automation applications. IndMALL provides this power supply with competitive pricing, easy quotation access, and dedicated customer support, ensuring your automation and control systems remain efficient, reliable, and protected without compromise.
