DRP024V240W3BA - Delta 240W 24V DIN Rail Power Supply
Technical Specifications of Delta DRP024V240W3BA 240W 24V DIN Rail Power Supply
| Brand | Delta |
| Product Type | SMPS |
| Product | DRP024V240W3BA |
Delta 240W 24V DIN Rail Power Supply DRP024V240W3BA Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 10A |
| Output Voltage | 24V |
| Output Voltage Adjustment Range | 24-28Vdc |
| Output Power | 240W |
| Line Regulation | < 0.5% (@ 3 x 320-600Vac input, 100% load) |
| Load Regulation | < 1.0% (@ 3 x 320-600Vac input, 0-100% load) |
| PARD | < 150mVpp |
| Start-up Time | < 1,000ms @ nominal input (100% load) |
| Hold-up Time | > 20ms @ 3 x 400Vac, > 40ms @ 3 x 500Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 5% @ 3 x 320-600Vac input, 0-100% load (Slew Rate: 0.1A/μs, 50% duty cycle @ 5Hz to 1KHz) |
| Start-up with Capacitive Loads | 10,000µF Max |
| Rise Time | < 100ms @ nominal input (100% load) |
| Nominal Input Voltage | 3 x 400-500Vac |
| Input Voltage Range | 3 x 320-600Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| DC Input Voltage Range | 450-800Vdc |
| Input Current | < 0.75A @ 3 x 400Vac, < 0.65A @ 3 x 500Vac |
| Efficiency at 100% load | > 91.0% @ 3 x 400Vac & 3 x 500Vac |
| Inrush Current | < 40A @ 3 x 400Vac & 3 x 500Vac |
| Power Factor at 100% load | - |
| Leakage Current | < 3.5mA @ 500Vac |
| Power Dissipation | 0% load: < 6.5W @ 3 x 400Vac & 3 x 500Vac 100% load: < 23.0W @ 3 x 400Vac & 3 x 500Vac |
| Case Chassis / Cover | Aluminium |
| Indicator | Green LED (DC OK) |
| Cooling System | Convection |
| Input Terminal | 4 Pins (Rated 600V/35A) |
| Output Terminal | 4 Pins (Rated 300V/28A) |
| Noise Sound Pressure Level (SPL) | < 40dBA |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input: AWG 18-12 Output: AWG 16-12 |
| Unit Weight | 0.89 kg (1.96 lb) |
| Operating Temperature | -25°C to +80°C |
| Storage Temperature | -40°C to +85°C |
| Power De-rating | Vertical: > 50°C de-rate power by 2.5% / °C, > 70°C de-rate power by 5% / °C Horizontal: > 40°C de-rate power by 2.5% / °C, > 60°C de-rate power by 5% / °C |
| Operating Humidity | 0 to 95% RH (Non-Condensing) |
| Shock Test (Non-Operating) | IEC 60068-2-27, 30G (300m/S²) for a duration of 18ms, 1 time per direction, 2 times in total |
| Vibration (Non-Operating) | IEC 60068-2-6, 10Hz to 500Hz @ 30m/S² (3G peak); 60 min per axis for all X, Y, Z direction |
| Operating Altitude | 0 to 2,500 Meters (8,200 ft.) for ITE application 0 to 2,000 Meters (6,560 ft.) for Industrial application |
| Pollution Degree | 2 |
| Bump Test (Operating) | IEC 60068-2-29, Half Sine Wave: 10G for a duration of 11ms, 1,000 times per direction, 6,000 times in total |
| Over Voltage Category | IlI According to IEC/EN 62477-1 / EN 60204-1 (clearance and creepage distances) and IEC 62103 (safety part) |
Obtain a Quote for Delta 240W 24V DIN Rail Power Supply DRP024V240W3BA at economical prices. Specifications Overview for DRP024V240W3BA reveals 10A Output Current, 24V Output Voltage, 240W Output Power at competitive prices. It operates with a nominal input voltage of 3 x 400-500Vac and supports an input voltage range of 3 x 320-600Vac. The power supply covers a nominal input frequency of 50-60Hz, with a broader input frequency range of 47-63Hz. With an input current of < 0.75A @ 3 x 400Vac, < 0.65A @ 3 x 500Vac, it ensures efficient performance. The unit features a Green LED (DC OK) indicator, aiding in quick status checks. Both input and output terminals have 4 Pins (Rated 600V/35A) and 4 Pins (Rated 300V/28A) for secure connections. Designed for extreme environments, it Operating Temperature from -25°C to +80°C and has a storage temperature of -40°C to +85°C. Take the First Step with a Quote for your requirement of 240W 24V DIN Rail Power Supply. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
