Delta DRP012V060W1AA - 5A 60W DIN Rail Power Supply
Technical Specifications of Delta DRP012V060W1AA 5A 60W DIN Rail Power Supply
| Brand | Delta |
| Product Type | SMPS |
| Product | DRP012V060W1AA |
Delta 5A 60W DIN Rail Power Supply DRP012V060W1AA Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 5A |
| Output Voltage | 12V |
| Output Voltage Adjustment Range | 11-14Vdc |
| Output Power | 60W |
| Line Regulation | < 0.5% (@ 85-264Vac input, 100% load) |
| Load Regulation | < 1% (@ 85-264Vac input, 0-100% load) |
| PARD | < 100mVpp |
| Start-up Time | < 2,500ms @ nominal input (100% load) |
| Hold-up Time | > 22ms @ 115Vac, > 110ms @ 230Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 5% @ 85-264Vac input, 0-100% load (Slew Rate: 0.1A/μs, 50% duty cycle @ 5Hz to 1KHz) |
| Start-up with Capacitive Loads | 8,000µF Max |
| Rise Time | < 20ms @ nominal input (100% load) |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 85-264Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| DC Input Voltage Range | 120-375Vdc |
| Input Current | < 1.35A @ 115Vac, < 0.80A @ 230Vac |
| Efficiency at 100% load | > 86.0% @ 115Vac & 230Vac |
| Inrush Current | < 50A @ 115Vac, < 100A @ 230Vac |
| Leakage Current | < 1mA @ 240Vac |
| Power Dissipation | 0% load: < 0.45W @ 115Vac, < 1.0W @ 230Vac 100% load: < 9.7W @ 115Vac & 230Vac |
| Case Chassis / Cover | Aluminium |
| Indicator | Green LED (DC OK) |
| Cooling System | Convection |
| Noise Sound Pressure Level (SPL) | < 40dBA |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input / Output: AWG 20-14 |
| Unit Weight | 0.33 kg (0.73 lb) |
| Operating Temperature | -20°C to +80°C |
| Storage Temperature | -25°C to +85°C |
| Power De-rating | Vertical / Horizontal: > 50°C de-rate power by 2.5% / °C, > 70°C de-rate by 4% / °C |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
| Shock Test (Non-Operating) | IEC 60068-2-27, 30G (300m/S²) for a duration of 18ms, 1 time per direction, 2 times in total |
| Vibration (Non-Operating) | IEC 60068-2-6, 10Hz to 500Hz @ 50m/S² (5G peak); 90 min per axis for all X, Y, Z direction |
| Operating Altitude | 0 to 2,000 Meters (6,560 ft) |
| Pollution Degree | 2 |
| Over Voltage Category | III According to IEC/EN 62477-1 (clearance and creepage distances) |
| Input Terminal | 3 Pins (Rated 300V/20A) |
| Output Terminal | 2 Pins (Rated 300V/20A) |
IndMALL Automation Dealing offers Delta 5A 60W DIN Rail Power Supply DRP012V060W1AA at unbeatable prices. The Main Technical Parameters of DRP012V060W1AA are 5A Output Current, 12V Output Voltage, 60W Output Power at competitive prices. It operates with a nominal input voltage of 100-240Vac and supports an input voltage range of 85-264Vac. The power supply covers a nominal input frequency of 50-60Hz, with a broader input frequency range of 47-63Hz. With an input current of < 1.35A @ 115Vac, < 0.80A @ 230Vac, it ensures efficient performance. The unit features a Green LED (DC OK) indicator, aiding in quick status checks for secure connections. Designed for extreme environments, it Operating Temperature from -20°C to +80°C and has a storage temperature of -25°C to +85°C. Take the First Step with a Quote for your requirement of 5A 60W DIN Rail Power Supply. Choose us for unparalleled pricing and support over other Dealers & Distributors.
