DRM-24V80W1PN - Delta 3.4A 81.6W DIN Rail Power Supply
Technical Specifications of Delta DRM-24V80W1PN 3.4A 81.6W DIN Rail Power Supply
| Brand | Delta |
| Product Type | SMPS |
| Product | DRM-24V80W1PN |
Delta3.4A 81.6W DIN Rail Power Supply DRM-24V80W1PN Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 3.4A |
| Output Voltage | 24V |
| Output Voltage Adjustment Range | 24-28Vdc |
| Output Power | 81.6W |
| Line Regulation | 10mV Max. (@ 85-276Vac input, 100% load) |
| Load Regulation | 100mV Max. (@ 85-276Vac input, 0-100% load) |
| PARD | 50mVpp Max. |
| Start-up Time | 430ms Max. @ 100Vac, 370ms Max. @ 120Vac, 330ms Max. @ 230Vac |
| Hold-up Time | 40ms Typ. @ 100Vac, 40ms Typ. @ 120Vac, 118ms Typ. @ 230Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | Β± 5% @ 0-100% load Slew rate 0.1A/Β΅s (@ 5Hz, 50Hz & 1kHz, 50% Duty Cycle) |
| Start-up with Capacitive Loads | 8,000Β΅F Max. |
| Rise Time | 15ms Max. @ 100Vac & 120Vac & 230Vac (0Β΅F, 24V, 3.4A) 55ms Max. @ 100Vac & 120Vac & 230Vac (5,000Β΅F, 24V, 10A) |
| Power Boost Duration | 5 seconds Typ. 7 seconds Max. |
| Power Boost Recovery Time | 14 seconds Typ. |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 85-276Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| Nominal DC Input Voltage | 110-300Vdc |
| DC Input Voltage Range | 88-375Vdc |
| Input Current | 0.91A Typ. @ 100Vac, 0.76A Typ. @ 120Vac, 0.44A Typ. @ 230Vac |
| Efficiency at 100% load | 90.95% Typ. @ 100Vac, 91.49% Typ. @ 120Vac, 91.31% Typ. @ 230Vac |
| Inrush Current | 6.0A Max. @ 100Vac, 7.0A Max. @ 120Vac, 13.0A Max. @ 230Vac |
| Power Factor at 100% load | 0.99 Typ. @ 100Vac, 0.98 Typ. @ 120Vac, 0.89 Typ. @ 230Vac |
| Leakage Current | (Enclosure to Neutral) < 0.14mA / 0.33mA @ 110Vac, 50Hz, TN/TT system / IT system < 0.20mA / 0.46mA @ 132Vac, 50Hz, TN/TT system / IT system < 0.36mA / 0.95mA @ 264Vac, 50Hz, TN/TT system / IT system |
| Power Dissipation | 0% load: 1.19W Typ. @ 100Vac, 1.19W Typ. @ 120Vac, 1.29W Typ. @ 230Vac 1.5W Max. @ 100Vac & 120Vac & 230Vac 100% load: 8.16W Typ. @ 100Vac, 7.63W Typ. @ 120Vac, 7.81W Typ. @ 230Vac 9.5W Max. @ 100Vac, 8.8W Max. @ 120Vac, 9.1W Max. @ 230Vac |
| Case Chassis / Cover | Aluminium |
| Indicator | Green LED (DC OK) and Red LED (Overload) |
| Cooling System | Convection |
| Input Terminal | 3 Pins (Rated 600V/35A) |
| Output Terminal | 6 Pins (Rated 300V/8A) |
| Noise Sound Pressure Level (SPL) | < 25dBA |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input: AWG 18-8 Output: AWG: 20-16 |
| Unit Weight | 0.50 kg (1.10 lb) |
| Operating Temperature | -25Β°C to +70Β°C (Cold start -40Β°C) |
| Storage Temperature | -40Β°C to +85Β°C |
| Power De-rating | Vertical Mounting: > 60Β°C de-rate power by 2.5% / Β°C Horizontal Mounting: > 50Β°C de-rate power by 2.5% / Β°C |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
| Shock Test (Non-Operating) | IEC60068-2-27, Half Sine Wave: 30G for a duration of 18ms; 3 times per direction, 6 times in total |
| Vibration (Non-Operating) | IEC 60068-2-6, Sine Wave: 10-500Hz; 3G peak; displacement of 0.35mm; 60 min per axis for all X, Y, Z directions |
| Operating Altitude | 0 to 5,000 Meters (16,400 ft.) for ITE application 0 to 2,500 Meters (8,200 ft.) for Industrial application |
| Pollution Degree | 2 |
| Bump Test (Operating) | IEC 60068-2-29, Half Sine Wave: 10G for a duration of 11ms, 1,000 times per direction, 6,000 times in total |
| Over Voltage Category | III According to IEC/EN 62477-1 / EN 60204-1 (clearance and creepage distances) and IEC 62103 (safety part) |
| Signal Terminal | - |
Get A Quote for Delta 3.4A 81.6W DIN Rail Power Supply DRM-24V80W1PN at the best price. Here are the brief Technical Specifications of DRM-24V80W1PN are 3.4A Output Current, 24V Output Voltage, 81.6W Output Power at competitive prices. It operates with a nominal input voltage of 100-240Vac and supports an input voltage range of 85-276Vac. The power supply covers a nominal input frequency of 50-60Hz, with a broader input frequency range of 47-63Hz. With an input current of 0.91A Typ. @ 100Vac, 0.76A Typ. @ 120Vac, 0.44A Typ. @ 230Vac, it ensures efficient performance. The unit features a Green LED (DC OK) and Red LED (Overload) indicator, aiding in quick status checks. Both input and output terminals have 3 Pins (Rated 600V/35A) and 6 Pins (Rated 300V/8A) for secure connections. Designed for extreme environments, it Operating Temperature from -25Β°C to +70Β°C (Cold start -40Β°C) and has a storage temperature of -40Β°C to +85Β°C. It's Time to get a Quote for your requirement of 3.4A 81.6W DIN Rail Power Supply. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
