PS2001-4810-1001 - Beckhoff Power Supply
Technical Specifications of Beckhoff Power Supply PS2001-4810-1001:
| Brand | Beckhoff |
| Product Type | Power Supply |
| Product | PS2001-4810-1001 |
PS2001-4810-1001 Beckhoff Power Supply Technical Specifications
| Specification | Value |
|---|---|
| Input voltage | AC 100...240 V, DC 110...150 V |
| Wide-range input | yes |
| Input current | typ. 2.23 A at 230 V AC |
| Switch-on current limiter | yes |
| Mains frequency | 50..60 Hz |
| Starting current | typ. 4.5 A peak at 230 V AC |
| Output voltage | 48 V DC |
| Adjustment range | 48...56 V DC |
| Output current | 10 A |
| Output | 480 W |
| Efficiency | approx. 96.3% |
| Weight | approx. 830 g |
| Approvals/markings | CE, UL, SEMI F47 |
| Protection rating | IP20 |
| Housing - Dimensions (W x H x D) | 48 mm x 124 mm x 127 mm |
| Housing - Material | aluminum |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Wiring | spring-loaded technique |
| Housing - Connection cross-section | input/output:e*: 0.5â¦6 mm²,f*: 0.5â¦4 mm²,a*: 0.5â¦4 mm² |
| Housing - Max. cable diameter with end sleeve | Input/Output: 2.8Â mm |
| Housing - Connection cross-section AWG | Input/Output: AWG20-10 |
| Housing - Stripping length | input/output: 10Â mm |
| Harmonic correction (PFC) | active |
| Extra power | 20% (continuously) |
| Precise fuse release | yes |
| Communication | EtherCAT |
| Bus interface | 2 x RJ45 |
| Data transfer medium | Ethernet/EtherCAT cable (min. Cat.5), shielded |
| Data transfer rates | 100 Mbit/s |
| Distance between stations | max. 100 m (100BASE-TX) |
