EL9210 - Beckhoff EtherCAT Terminals System

Name: Beckhoff EL9210
Brand: Beckhoff
SKU: EL9210
Rating: 4.1 (4 reviews)

EL9210 Beckhoff EtherCAT Terminals System Technical Specifications

EL9210 Beckhoff EtherCAT Terminals System Technical Specifications

Specification	Value
Technology	potential supply terminal with diagnostics and fuse
Housing width	12Â mm
Weight	approx. 55 g
Operating temperature	-25....+60°C
Storage temperature	-40....+85°C
Approvals/markings	CE, CCC, UL, ATEX, IECEx, DNV GL
Ex marking	ATEX:II 3 G Ex ec IIC T4 GcIECEx:Ex ec IIC T4 Gc
Current load	â¤ 10 A
Nominal voltage	24 V DC
Electrical isolation	500 V (E-bus/field potential)
Connection facility to additional power contact	1
Bit width in the process image	2
Housing - Design form	compact terminal housing with signal LEDs
Housing - Material	polycarbonate
Housing - Dimensions (W x H x D)	12 mm x 100 mm x 68 mm
Housing - Installation	on 35 mm DIN rail, conforming to EN 60715 with lock
Housing - Side by side mounting by means of	double slot and key connection
Housing - Marking	labeling of the BZxxxx series
Housing - Wiring	solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver
Housing - Connection cross-section	s: 0.08...2.5mm²,st: 0.08...2.5 mm²,f*: 0.14...1.5 mm²
Housing - Connection cross-section AWG	s: AWG28...14,st: AWG28...14,f*: AWG26...16
Housing - Stripping length	8....9 mm
Housing - Current load power contacts	Imax: 10 A
Power LED	green
Renewed infeed	yes
PE contact	yes
Current consumption E-bus	typ. 90 mA
Diagnostics in the process image	yes
Reported to E-bus	yes
Defect LED	red
Integrated fine-wire fuse	â¦6.3 A
