EL9221-6040 - Beckhoff EtherCAT Terminals System
EL9221-6040 Beckhoff EtherCAT Terminals System Technical Specifications
| Brand | Beckhoff |
| Product Type | EtherCAT Terminals System |
| Product | EL9221-6040 |
EL9221-6040 Beckhoff EtherCAT Terminals System Technical Specifications
| Specification | Value |
|---|
| Technology | overcurrent protection terminal 24Â VÂ DC, 1-channel |
| Special features | output additionally via power contact, LED button |
| Weight | approx. 55 g |
| Operating temperature | -25....+60°C |
| Storage temperature | -40....+85°C |
| Approvals/markings | CE, UL |
| Nominal voltage | 24 V DC |
| Electrical isolation | 500 V (E-bus/signal voltage) |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 12 mm x 100 mm x 68 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Marking | labeling of the BZxxxx series |
| Housing - Wiring | solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver |
| Housing - Connection cross-section | s*: 0.08...2.5mm²,st*: 0.08...2.5 mm²,f*: 0.14...1.5 mm² |
| Housing - Connection cross-section AWG | s*: AWG28...14,st*: AWG28...14,f*: AWG26...16 |
| Housing - Stripping length | 8....9 mm |
| Housing - Current load power contacts | Imax: 10 A |
| Current consumption E-bus | typ. 80 mA |
| Protect. rating/installation pos. | IP20/see documentation |
| Number of outputs | 1 |
| Input current | max. 10 A |
| Rated current | 4 A |
| Number of inputs | 1 |
| Hold after output switch-off | ≥10 s |
| Advance warning output load | 90% |
| Integrated fail-safe element | 6Â AÂ (T) |
| Over voltage power-off | ≥ 32 V DC |
