Baumer OT500.GL-PLPLB.72F Photoelectric Sensor
The Baumer OT500.GL-PLPLB.72F Photoelectric Sensor offers a Rectangular design, 150 β¦ 2500 mm sensing distance, PNP output, and Connector M12 5 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the Background Suppression type.
| Sensing distance Tw | 150 β¦ 2500 mm |
| Sensing range Tb | 100 β¦ 2625 mm |
| Output circuit | PNP |
| Connection types | Connector M12 5 pin |
Baumer OT500.GL-PLPLB.72F Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Background suppression |
| Sensing distance Tw | 150 β¦ 2500 mm |
| Sensing range Tb | 100 β¦ 2625 mm |
| Power on indication | LED green |
| Output indicator | LED yellow / LED red |
| Sensing distance adjustment | qTeach / external |
| Suppression of reciprocal influence | Yes |
| Alignment optical axis | < 1Β° |
| Light source | Pulsed red laser diode |
| Wave length | 680 nm |
| Response time / release time | < 8 ms |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Current consumption max. (no load) | 60 mA |
| Voltage drop Vd | <2 VDC |
| Output function | Light operate, switchable |
| Output circuit | PNP |
| Output current | 50 mA, sum of all outputs |
| Short circuit protection | Yes |
| Width / diameter | 18 mm |
| Height / length | 45 mm |
| Depth | 32 mm |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Connector M12 5 pin |
| Protection class | IP 67 |
| Operating temperature | -20 β¦ +50 Β°C |
Give Us a Call for Baumer 680nm Wave length Diffuse Sensor OT500.GL-PLPLB.72F part no: 11248945 at the lowest pricing. In-depth Technical Analysis of OT500.GL-PLPLB.72F, 11248945 feature Background suppression Sensor, engineered for precise detection with a sensing distance (Tw) of 150 β¦ 2500 mm. The sensor features qTeach / external adjustment for flexible setup and utilizes an Pulsed red laser diode light source with a wavelength of 680 nm. It boasts a fast response time of less than < 8 ms, and operates within a voltage supply range of 12 β¦ 30 VDC, with a typical current consumption of . The output function supports Light operate, switchable with a PNP output circuit and can handle an output current of up to 50 mA, sum of all outputs. Measuring 18 mm in width, 45 mm in height, and 32 mm in depth, this compact Rectangular sensor is connected via a Connector M12 5 pin. Elevate Your Project with a Quote for your requirement of Baumer 680nm Wave length Diffuse Sensor. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
