Baumer OT500.DL-GLIAJ.72F Ultrasonic Distance Sensor
The Baumer OT500.DL-GLIAJ.72F Laser Distance Sensor offers a Rectangular design, 150 β¦ 2500 mm scanning range, Analog 4 ... 20 mA, Push-pull / IO-Link output, and Connector M12 5 pin connection. Manufactured by Baumer under the Baumer Laser Distance Sensor category, this model belongs to the OT500 Series.
| Measuring distance Sd | 150 β¦ 2500 mm |
| Measuring range Mr | 2350 mm |
| Output circuit | Analog 4 ... 20 mA, Push-pull / IO-Link |
Baumer OT500.DL-GLIAJ.72F Ultrasonic Distance Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Distance measuring |
| Measuring distance Sd | 150 β¦ 2500 mm |
| Measuring range Mr | 2350 mm |
| Adjustment | Teach-in and IO-Link |
| Power on indication | LED green |
| Output indicator | LED yellow |
| Repeat accuracy | β€ 1200 β¦ 4300 Β΅m |
| Linearity error | Β± 10 mm |
| Beam type | Point |
| Temperature drift | Β± 15 mm |
| Light source | Pulsed red laser diode |
| Wave length | 680 nm |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Current consumption max. (no load) | 60 mA |
| Output circuit | Analog 4 ... 20 mA, Push-pull / IO-Link |
| Interface | IO-Link V1.1.3 |
| Baud rate | 230.4 kBaud (COM 3) |
| Width / diameter | 18 mm |
| Height / length | 45 mm |
| Depth | 32 mm |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Connector M12 5 pin |
| Protection class | IP 67 |
| Operating temperature | -20 β¦ +50 Β°C |
| Load resistance | < (+Vs - 6 V) / 0,02 A |
| Output current | 50 mA (push-pull) |
| Switching output | Light operate, switchable |
Reach Us by Email for Baumer Distance Measurement Sensor OT500.DL-GLIAJ.72F part no: 11240053 at Discounted Rates. Key Technical Features of OT500.DL-GLIAJ.72F, 11240053 are distance range of 150 β¦ 2500 mm. This sensor utilizes Teach-in and IO-Link with a LED green power-on indicator. The Point type is point-based, using a Pulsed red laser diode at a wavelength of 680 nm. The sensor operates within a voltage supply range of 12 β¦ 30 VDC, with a maximum current consumption of 60 mA. The compact Rectangular design measures 18 mm in width, 45 mm in height, and 32 mm in depth, offering easy installation in tight spaces. Constructed with durable Plastic (ASA, PMMA) housing, the front optics are made of PMMA for enhanced protection. The sensor connects via an Connector M12 5 pin making it ideal for industrial applications requiring high precision. Navigate Your Needs with a Quote for your requirement of Baumer Distance Measurement Sensor. Our pricing and support are unrivaled, especially when compared to other Competitors.
