OT300.DL-UBZZB.72N: 11240055 - Baumer Laser Distance Sensor With Analog Output
Technical Specifications of Baumer Laser Distance Sensor With Analog Output OT300.DL-UBZZB.72N 11240055:
| Spec | Value |
|---|---|
| Type | Distance measuring |
| Measuring distance Sd | 100 … 1800 mm |
| Output circuit | Analog 0 ... 10 VDC |
| Connection types | Connector M8 4 pin |
Baumer Laser Distance Sensor With Analog Output OT300.DL-UBZZB.72N, 11240055 Technical Specifications:
| Specification | Value |
|---|---|
| Type | Distance measuring |
| Version | Time of Flight |
| Measuring distance Sd | 100 … 1800 mm |
| Adjustment | qTeach / external |
| Power on indication | LED green |
| Light indicator | |
| Resolution | |
| Linearity error | ± 10 mm |
| Beam type | Point |
| Alignment optical axis | < 2° |
| Temperature drift | ± 15 mm |
| Light source | Pulsed red laser diode |
| Wave length | 680 nm |
| Response time / release time | < 8 ms |
| Current consumption max. (no load) | 60 mA |
| Voltage drop Vd | |
| Output circuit | Analog 0 ... 10 VDC |
| Output current | |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes, Vs to GND |
| Interface | |
| Baud rate | |
| Cycle time | |
| Process data length | |
| Width / diameter | 12.9 mm |
| Height / length | 32.3 mm |
| Depth | 23 mm |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Connector M8 4 pin |
| Protection class | IP 67 |
| Operating temperature | -20 … +50 °C |
Talk to Our Engineer for Baumer Laser Distance Sensor With Analog Output OT300.DL-UBZZB.72N part no: 11240055 with exclusive offers. Core System Specifications of OT300.DL-UBZZB.72N, 11240055 are Distance measuring Sensor with Time of Flight capabilities, designed for accurate detection with a measuring distance of 100 … 1800 mm. The sensor allows easy adjustment through qTeach / external, featuring a LED green power-on indication for operational clarity. It utilizes a Pulsed red laser diode with a wavelength of 680 nm and a response time of less than < 8 ms. Operating within a voltage supply range of 12 … 30 VDC, the sensor has a maximum current consumption of 60 mA when idle. The Analog 0 ... 10 VDC output circuit ensures flexibility in integration. Measuring 12.9 mm in width, 32.3 mm in height, and 23 mm in depth, the compact Rectangular design makes it easy to install. It comes equipped with a durable Connector M8 4 pin for secure connections. Don't Miss Out on a Quote for your requirement of Baumer Laser Distance Sensor With Analog Output. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
