Baumer OADM 250I1101/S14C Ultrasonic Distance Sensor
The Baumer OADM 250I1101/S14C Laser Distance Sensor offers a Rectangular design, 200 β¦ 4000 mm scanning range, Analog output, and Connector M12 5 pin, rotatable connection. Manufactured by Baumer under the Baumer Laser Distance Sensor category, this model belongs to the OADM Series.
| Measuring distance Sd | 200 β¦ 4000 mm |
| Output circuit | Analog |
Baumer OADM 250I1101/S14C Ultrasonic Distance Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Measuring distance Sd | 200 β¦ 4000 mm |
| Adjustment | Teach-in: button / external |
| Power on indication | LED green |
| Beam type | Point |
| Light source | Pulsed red laser diode |
| Wave length | 660 nm |
| Voltage supply range +Vs | 15 β¦ 28 VDC |
| Current consumption max. (no load) | 250 mA (typ. 110 mA @ 24V) |
| Output circuit | Analog |
| Width / diameter | 25.4 mm |
| Height / length | 66 mm |
| Depth | 51 mm |
| Design | Rectangular |
| Housing material | Aluminum |
| Front (optics) | Glass |
| Connection types | Connector M12 5 pin, rotatable |
| Ambient light immunity | < 40 kLux |
| Protection class | IP 67 |
| Operating temperature | -25 β¦ +50 Β°C |
| Output signal | 4 ... 20 mA |
| Output current | 100 mA |
Please speak to our Technical Engineer for Baumer 4000 mm Measuring Distance Sensor OADM 250I1101/S14C part no: 11007211 at attractive prices. Technical Specs Summary of OADM 250I1101/S14C, 11007211 includes distance range of 200 β¦ 4000 mm. This sensor utilizes Teach-in: button / external with a LED green power-on indicator. The Point type is point-based, using a Pulsed red laser diode at a wavelength of 660 nm. The sensor operates within a voltage supply range of 15 β¦ 28 VDC, with a maximum current consumption of 250 mA (typ. 110 mA @ 24V). The compact Rectangular design measures 25.4 mm in width, 66 mm in height, and 51 mm in depth, offering easy installation in tight spaces. Constructed with durable Aluminum housing, the front optics are made of Glass for enhanced protection. The sensor connects via an Connector M12 5 pin, rotatable making it ideal for industrial applications requiring high precision. Match Your Needs with a Quote for your requirement of Baumer 4000 mm Measuring Distance Sensor. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
