Baumer OM20-P0026.HH.TXN Ultrasonic Distance Sensor
The Baumer OM20-P0026.HH.TXN Laser Distance Sensor offers a Rectangular, front view design, 16 β¦ 26 mm scanning range, RS485 output, and Connector M8 4 pin connection. Manufactured by Baumer under the Baumer Laser Distance Sensor category, this model belongs to the OM20 Series.
| Measuring distance Sd | 16 β¦ 26 mm |
| Measuring range Mr | 10 mm |
| Output circuit | RS485 |
Baumer OM20-P0026.HH.TXN Ultrasonic Distance Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Distance measuring |
| Measuring distance Sd | 16 β¦ 26 mm |
| Measuring range Mr | 10 mm |
| Adjustment | Teach-in: button / RS485 |
| Power on indication | LED green |
| Output indicator | LED yellow |
| Repeat accuracy | 1 Β΅m |
| Linearity error | Β± 0.08 % Mr |
| Beam type | Point |
| Temperature drift | 0,01 % Sde/K |
| Light source | Pulsed red laser diode |
| Wave length | 660 nm |
| Maximum pulse power | 1 mW |
| Pulse duration | 0.001 ... 1 ms |
| Pulse period | 0.2 ... 3.4 ms |
| Response delay | 0.4 ms |
| Measuring frequency | 5000 Hz |
| Voltage supply range +Vs | 12 β¦ 28 VDC |
| Current consumption max. (no load) | 50 mA |
| Output circuit | RS485 |
| Interface | RS485 |
| Baud rate | 57600, adjustable |
| Protocol | Modbus RTU |
| Width / diameter | 13 mm |
| Height / length | 37 mm |
| Depth | 34.5 mm |
| Design | Rectangular, front view |
| Housing material | Die-cast zinc |
| Front (optics) | Glass |
| Connection types | Connector M8 4 pin |
| Ambient light immunity | < 100 kLux |
| Protection class | IP 67 |
| Operating temperature | -10 β¦ +50 Β°C |
| Weight | 41 g |
Get A Quote for Baumer Laser Distance Sensor Rs485 OM20-P0026.HH.TXN part no: 11233538 at the best price. Here are the brief Technical Specifications of OM20-P0026.HH.TXN, 11233538 are distance range of 16 β¦ 26 mm. This sensor utilizes Teach-in: button / IO-Link with a LED green power-on indicator. The Point type is point-based, using a Pulsed red laser diode at a wavelength of 660 nm. The sensor operates within a voltage supply range of 12 β¦ 28 VDC, with a maximum current consumption of 50 mA. The compact Rectangular, front view design measures 13 mm in width, 37 mm in height, and 34.5 mm in depth, offering easy installation in tight spaces. Constructed with durable Die-cast zinc housing, the front optics are made of Glass for enhanced protection. The sensor connects via an Connector M8 4 pin making it ideal for industrial applications requiring high precision. It's Time to get a Quote for your requirement of Baumer Laser Distance Sensor Rs485. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
