Baumer OADM 250U1101/S14C Ultrasonic Distance Sensor
The Baumer OADM 250U1101/S14C Laser Distance Sensor offers a Rectangular design, 200 β¦ 4000 mm scanning range, Analog output, and Connector M12 5 pin, rotatable connection. Manufactured by Baumer under the Baumer Laser Distance Sensor category, this model belongs to the OADM Series.
| Measuring distance Sd | 200 β¦ 4000 mm |
| Output circuit | Analog |
Baumer OADM 250U1101/S14C Ultrasonic Distance Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Measuring distance Sd | 200 β¦ 4000 mm |
| Adjustment | Teach-in: button / external |
| Power on indication | LED green |
| Beam type | Point |
| Light source | Pulsed red laser diode |
| Wave length | 660 nm |
| Voltage supply range +Vs | 15 β¦ 28 VDC |
| Current consumption max. (no load) | 250 mA (typ. 110 mA @ 24V) |
| Output circuit | Analog |
| Width / diameter | 25.4 mm |
| Height / length | 66 mm |
| Depth | 51 mm |
| Design | Rectangular |
| Housing material | Aluminum |
| Front (optics) | Glass |
| Connection types | Connector M12 5 pin, rotatable |
| Ambient light immunity | < 40 kLux |
| Protection class | IP 67 |
| Operating temperature | -25 β¦ +50 Β°C |
| Output signal | 0 ... 10 VDC |
| Output current | 100 mA |
Send Your Inquiry for Baumer Adjustment Distance Sensor OADM 250U1101/S14C part no: 11007212 with cost-effective solutions. Essential Technical Specs of OADM 250U1101/S14C, 11007212 are distance range of 200 β¦ 13000 mm. This sensor utilizes Teach-in: button / external with a LED green power-on indicator. The Point type is point-based, using a Pulsed red laser diode at a wavelength of 660 nm. The sensor operates within a voltage supply range of 15 β¦ 28 VDC, with a maximum current consumption of 250 mA (typ. 110 mA @ 24V). The compact Rectangular design measures 25.4 mm in width, 66 mm in height, and 51 mm in depth, offering easy installation in tight spaces. Constructed with durable Aluminum housing, the front optics are made of Glass for enhanced protection. The sensor connects via an Connector M12 5 pin, rotatable making it ideal for industrial applications requiring high precision. Capture the Best Deal with a Quote for your requirement of Baumer Adjustment Distance Sensor. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
