Baumer O300.DI-GM1J.72N Photoelectric Sensor
The Baumer O300.DI-GM1J.72N Photoelectric Sensor offers a Rectangular design, 30 β¦ 300 mm measuring distance, 10 β¦ 30 VDC supply voltage, Push-pull output, and Connector M8 4 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O300/O500 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Model Number | O300.DI-GM1J.72N |
Baumer O300.DI-GM1J.72N Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Distance measuring |
| Version | IO-Link measuring |
| Measuring distance Sd | 30 β¦ 300 mm |
| Adjustment | Teach-in and IO-Link |
| Power on indication | LED green |
| Light indicator | LED yellow |
| Resolution | 500 β¦ 5000 Β΅m |
| Linearity error | Β± 1.5 β¦ 15 mm |
| Beam type | Point |
| Alignment optical axis | < 2Β° |
| Temperature drift | < 0,2 % Sde/K |
| Light source | Pulsed infrared diode |
| Wave length | 860 nm |
| Response time / release time | < 0.49 ms |
| Current consumption max. (no load) | 45 mA |
| Voltage drop Vd | <3 VDC |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Interface | IO-Link V1.1 |
| Baud rate | 38.4 kBaud (COM 2) |
| Cycle time | β₯ 2.7 ms |
| Process data length | 3 Byte |
| Width / diameter | 12.9 mm |
| Height / length | 32.3 mm |
| Depth | 23 mm |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Connector M8 4 pin |
| Protection class | IP 67 |
| Operating temperature | -25 β¦ +60 Β°C |
Ask for the Pricing of Baumer Laser Sensor With Push-Pull Output O300.DI-GM1J.72N part no: 11199081 at unbeatable prices. Detailed Specifications of O300.DI-GM1J.72N, 11199081 feature Distance measuring Sensor with IO-Link measuring capabilities, designed for accurate detection with a measuring distance of 30 β¦ 300 mm. The sensor allows easy adjustment through Teach-in and IO-Link, featuring a LED green power-on indication for operational clarity. It utilizes a Pulsed infrared diode with a wavelength of 860 nm and a response time of less than < 0.49 ms. Operating within a voltage supply range of 10 β¦ 30 VDC, the sensor has a maximum current consumption of 45 mA when idle. The Push-pull output circuit ensures flexibility in integration. Measuring 12.9 mm in width, 32.3 mm in height, and 23 mm in depth, the compact Rectangular design makes it easy to install. It comes equipped with a durable Connector M8 4 pin for secure connections. Now's the Time to Secure a Quote for your requirement of Baumer Laser Sensor With Push-Pull Output. We're committed to offering more favorable pricing and more responsive support than other Traders.
