Baumer HMG10-B - Incremental Rotary Encoder
The Baumer HMG10-B - Incremental Rotary Encoder offers a ø105 mm size, 1 … 131072 ppr, Magnetic method, and Terminal box, Flange connector M23 connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the Heavyduty Incremental Encoder.
| Sensing Method | Magnetic |
| Switching Outputs | 1 output (Open collector) |
| Connection | Terminal box, Flange connector M23 |
Baumer HMG10-B - Incremental Rotary Encoder – Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 4.75...30 VDC |
| Short-circuit proof | Yes |
| Consumption w/o load | ≤100 mA |
| Initializing time | ≤ 500 ms after power on |
| Pulses per revolution | 1 … 131072 |
| Phase shift | 90 ° ±20° |
| Duty cycle | 40…60 % |
| Reference signal | Zero pulse, width 90° |
| Sensing method | Magnetic |
| Output signals | A+, B+, R+, A-, B-, R-, Error output nE+, nE- |
| Output stages | TTL/HTL (Vin = Vout) |
| Programming interface | RS485 (≤600 m) |
| Programmable parameters | Pulse number, Switch-off and switch-on speeds, Switching delay time |
| Diagnostic function | Function control |
| Status indicator | 4 LEDs in device back side |
| Switching accuracy | ± 2 % (or 1 Digit) |
| Switching outputs | 1 output (Open collector) |
| Output switching capacity | 30 VDC; ≤100 mA |
| Switching hysteresis | 10 … 100 % adjustable |
| Switching delay time | ≤20 ms |
| Size (flange) | ø105 mm |
| Shaft type | ø16...20 mm (blind hollow shaft), ø17 mm (cone shaft 1:10) |
| Admitted shaft load | ≤450 N axial, ≤650 N radial |
| Flange | Support plate for torque arm, 360° freely positionable |
| Protection EN 60529 | IP 66 / IP 67 |
| Operating speed | ≤12000 rpm |
| Range of switching speed | ns (off) = ±2...12000 rpm, factory setting 6000 rpm |
| Operating torque typ. | 10 Ncm |
| Rotor moment of inertia | 950 gcm² |
| Material | Housing: aluminium alloy, Shaft: stainless steel |
| Operating temperature | -40...+95 °C |
| Relative humidity | 95 % non-condensing |
| Resistance | IEC 60068-2-6, Vibration 30 g, 10-2000 Hz, IEC 60068-2-27, Shock 400 g, 1 ms |
| Corrosion protection | IEC 60068-2-52 Salt mist, for ambient conditions CX (C5-M) according to ISO 12944-2 |
| Connection | Terminal box, Flange connector M23 |
| Weight approx. | 1.6 kg |
Get A Quote for Baumer Encoder With Blind Hollow Shaft HMG10-B - Incremental part no: 11043628 at the best price. Here are the brief Technical Specifications of HMG10-B - Incremental, 11043628 are voltage supply of 4.75...30 VDC and pulses per revolution ranging from 1 … 131072. The encoders provide a phase shift of 90 ° ±20° and a duty cycle of 40…60 %, with a Zero pulse, width 90°. Using Magnetic sensing technology, the encoders offer output signals including A+, B+, R+, A-, B-, R-, Error output nE+, nE-. The available output stages are TTL/HTL (Vin = Vout), ensuring versatile performance. The encoders come in an ø105 mm flange size and operate at speeds of up to -40...+95 °C. Constructed with a durable Housing: aluminium alloy, Shaft: stainless steel, they offer connections via Terminal box, Flange connector M23. It's Time to get a Quote for your requirement of Baumer Encoder With Blind Hollow Shaft. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
