FVDK 10P66Y0/S35A: 11045447 - Baumer Plastic Fibre Optic Sensor
Technical Specifications of Baumer Plastic Fibre Optic Sensor FVDK 10P66Y0/S35A 11045447:
| Spec | Value |
|---|---|
| Sensing distance Tw | 130 mm |
| Response time / release time | 0.25 … 1 ms (adjustable) |
| Output circuit | PNP |
| Connection Types | Connector M8 4 pin |
Baumer Plastic Fibre Optic Sensor FVDK 10P66Y0/S35A, 11045447 Technical Specifications:
| Specification | Value |
|---|---|
| Type | - |
| Actual range Sb (FSE 200C1002) | 340 mm |
| Sensing distance Tw | 130 mm |
| Light source | Pulsed red LED |
| Light indicator | 2 x 4-digit display |
| Wave length | 645 nm |
| Response time / release time | 0.25 … 1 ms (adjustable) |
| Voltage supply range +Vs | 10.8 … 26.4 VDC |
| Current consumption max. (no load) | 30 mA |
| Output function | Light / dark operate switchable |
| Output circuit | PNP |
| Output current | 100 mA |
| Fiber optic head | - |
| Width / diameter (head) | 10 mm |
| Height / length (head) | 33.8 mm |
| Depth | 70.2 mm |
| Design | Rectangular |
| Housing material | Polycarbonate/ABS |
| Connection types | Connector M8 4 pin |
| Material (head) | - |
| Bending radius | - |
| Cable jacket diameter | - |
| Material cable jacket | - |
| Material (fiber optic cable) | - |
| Length (fiber optic cable) | - |
| Operating temperature | -20 … +55 °C |
| Protection class | IP 40 |
IndMALL Automation Dealing offers Baumer Plastic Fibre Optic Sensor FVDK 10P66Y0/S35A, part no: 11045447 at unbeatable prices. The Main Technical Parameters of FVDK 10P66Y0/S35A, 11045447 feature operates with a pulsed red LED at 645 nm and provides an adjustable response time of 0.25 to 1 ms. It features a sensing range of 340 mm, with a typical range of 130 mm. The sensor includes a 2 x 4-digit display for easy reading and operates on a 10.8-26.4 VDC power supply, consuming 30 mA. It supports light/dark operate switching with PNP output, handling up to 100 mA. The rectangular housing is made of polycarbonate/ABS, with dimensions of 10 mm x 33.8 mm x 70.2 mm. The sensor uses an M8 4-pin connector and has an IP40 rating, making it suitable for indoor applications. Operating in temperatures from -20 to +55°C, this sensor ensures reliable performance. Take the First Step with a Quote for your requirement of Baumer Plastic Fibre Optic Sensor. Choose us for unparalleled pricing and support over other Dealers & Distributors.
