Autonics TCN4S-22R Dual Display PID Temperature Controller
The TCN4S-22R Autonics Dual Display PID Temperature Controllers unit operates on 24VAC/DC power with 100ms sampling cycle and relay output. Manufactured by Autonics, this controller belongs to the TC Series of Autonics Dual Display PID Temperature Controllers used in industrial automation across India. It features 4-digit 7-segment LED display, ON/OFF, P, PI, PD, PID control methods, proportional band 0.1 to 999.9℃/℉, integral time 0 to 9999 sec, derivative time 0 to 9999 sec, control period 0.5 to 120.0 sec, manual reset 0.0 to 100.0%, and approximately 147g weight.
| Brand | Autonics |
| Product Type | Temperature Controller |
| Model Number | TCN4S-22R |
Autonics TCN4S-22R Dual Display PID Temperature Controller - Technical Specifications
| Specification | Value |
|---|---|
| Power supply | 24VAC~ 50/60Hz, 24-48VDC |
| Sampling cycle | 100ms |
| Control output | Relay(250VAC~ 3A) or SSR drive(12VDC) [ON/OFF] |
| Display method | 4-digit 7-segment LED |
| Control method | ON/OFF, P, PI, PD, PID |
| Proportional band | 0.1 to 999.9℃/℉ |
| Integral time | 0 to 9999 sec |
| Derivative time | 0 to 9999 sec |
| Control period | 0.5 to 120.0 sec |
| Manual reset | 0.0 to 100.0% |
| Environment_Ambient temperature | -10 to 50℃, storage: -20 to 60℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Insulation type | Double insulation or reinforced insulation(mark: @(INS), dielectric strength between the measuring input part and the power part: AC power 2kV, AC/DC Power 1kV) |
| Input specification | Thermocouple: K(CA), J(IC), T(CC), R(PR), S(PR), L(IC)RTD: DPt100Ω, Cu50Ω |
| Option output | Alarm 1/2 |
| Display accuracy_RTD | •At room temperature(23ºC ± 5ºC):(PV ± 0.5% or ±1ºC, select the higher one) ± 1-digit•Out of room temperature range:(PV± 0.5% or ±2ºC, select the higher one)± 1-digit |
| Display accuracy_Thermocouple | •At room temperature(23ºC ± 5ºC):(PV ± 0.5% or ±1ºC, select the higher one) ± 1-digit•Out of room temperature range:(PV± 0.5% or ±2ºC, select the higher one)± 1-digit |
| Hysteresis(adjustable sensitivity) | 1 to 100℃/℉(0.1 to 50.0℃/℉) variable |
| Weight | Approx. 147g(approx. 100g) |
The TCN4S-22R Autonics Dual Display PID Temperature Controllers device is used for temperature regulation in industrial automation systems. It operates on 24VAC/DC power supply, supports a 100ms sampling cycle, and provides a 4-digit 7-segment LED display for monitoring temperature values. With relay or SSR drive control output, this model belongs to the TC Series and supports stable PID temperature control.
In industrial facilities across India, the TCN4S-22R is applied in heating equipment, packaging machines, plastic molding systems, and automated manufacturing lines. The PID control method and adjustable control period help maintain consistent temperature conditions during production processes. The dual display structure allows operators to monitor both process value and set value directly from the controller.
The TCN4S-22R Autonics Dual Display PID Temperature Controllers unit provides dependable temperature monitoring with configurable PID parameters and stable sampling performance. As part of the TC Series manufactured by Autonics, it supports industrial automation applications requiring controlled heating and process temperature regulation. This model is suitable for panel-mounted temperature control in industrial machinery.
