Autonics SRHL1-1410 Solid State Relay
The Autonics SRHL1-1410 Solid State Relay offers Single-phase, Panel, DIN rail mounting type, 10A load current, 10-30VDC input voltage. Manufactured by Autonics under the Autonics Solid State Relay category, this model belongs to the , SRHL1 Series.
| Brand | Autonics |
| Product Type | Solid State Relay |
| Model Number | SRHL1-1410 |
Autonics SRHL1-1410 Solid State Relay β Technical Specifications
| Specification | Value |
|---|---|
| Control phase | Single-phase |
| Mounting type | Panel, DIN rail |
| Rated input voltage | 10-30VDC |
| Rated load voltage | 48-480VAC~ |
| Dielectric strength | Input-output: 2500VAC 50/60Hz for 1 min. Input/output-case: 4000VAC 50/60Hz for 1 min |
| Rated load current | 10A |
| Function | Zero cross turn-on |
| Heatsink | Heatsink |
| Alarm(Overheat Prevention) | Alarm indicator |
| Environment_Ambient temperature | -30 to 70β, storage: -30 to 100β(The rated load current capacity is different depending on ambient temperature. Refer to 'β£ SSR Derating Curve'.) |
| Environment_Ambient humidity | 45 to 85% RH, storage: 45 to 85% RH |
| Weight | Approx. 270g(approx.192g) |
Send Your Inquiry for Single-Phase Solid State Relays SRHL1-1410 with cost-effective solutions. Essential Technical Specs of SRHL1-1410 are controllers support Single-phase operation and are designed for Panel, DIN rail mounting, ensuring easy installation and compatibility with various setups. They operate with a rated input voltage of 10-30VDC and a rated load voltage of 48-480VAC~, providing reliable performance across diverse applications. Featuring a high dielectric strength of Input-output: 2500VAC 50/60Hz for 1 min. Input/output-case: 4000VAC 50/60Hz for 1 min these controllers ensure enhanced safety and durability. With a rated load current of 10A, they deliver robust handling of demanding loads. The ambient humidity range of 45 to 85% RH, storage: 45 to 85% RH makes them suitable for various environmental conditions. Weighing Approx. 270g(approx.192g), they offer a lightweight yet sturdy design. Capture the Best Deal with a Quote for your requirement of Single-Phase Solid State Relays. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
