Autonics PR30-10DP Proximity Sensor
The Autonics PR30-10DP Proximity Sensor delivers a 10mm sensing distance with PNP Normally Open output and a rugged M30 sensing side diameter for reliable metal detection in automation. Manufactured by Autonics, this proximity sensor under the PR Series ensures high performance with hysteresis max. 10 of sensing distance and a standard sensing target 30Γ30Γ1mm (iron). It operates on a DC 3-wire type 12β24VDC power supply, supports a 400Hz response frequency, and features durable IP67 protection suitable for industrial environments.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PR30-10DP |
Autonics PR30-10DP Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M30 |
| Sensing distance | 10mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 30Γ30Γ1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | PNP Normally Open |
| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Installation | Flush |
| Cable Standard/material | Standard cable |
| Body length | Standard type |
| Residual voltage | Max. 1.5V |
| Environment_Ambient temperature | -25 to 70β, storage: -30 to 80β |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Γ 8 mm: SUS303),washer: Nikel plated Iron, sensing side: polybutylene terephthalate,standard cable (black): polyvinyl chloride (PVC),oil resistant cable (gray): oil resistant polyvinyl chloride (PVC) |
| Response frequency | 400Hz |
| Weight | Approx. 207g(approx. 170g) |
The Autonics PR30-10DP offers a 10mm sensing distance in an M30 flush housing, powered by DC 12β24V three-wire configuration with PNP Normally Open output. With low current consumption under 10mA and a fast 400Hz response, it ensures precise object detection in high-speed production lines. More options are available at Autonics Proximity Sensors.
The Autonics PR30-10DP is engineered with nickel-plated brass construction and IP67 protection, making it resistant to oil, dust, and water in challenging conditions. It operates between -25Β°C to 70Β°C with 95% humidity tolerance, maintaining reliable performance across Indian factory environments. For engineers seeking product variations, see Autonics Proximity Sensors PR Series.
The PR30-10DP is widely used for conveyor positioning, stamping machine detection, packaging lines, and robotic assembly stations. Its flush mounting avoids false triggers while ensuring high accuracy. Maintenance engineers rely on its stable sensing, while panel designers prefer its compatibility with industrial PLCs.
Trusted by wholesalers, dealers, and distributors, the Autonics PR30-10DP provides durability, accuracy, and smooth integration, making it a dependable Cylindrical Inductive Proximity Sensor. This model supports industries that demand rugged and precise sensing across automation projects.
