Autonics MT4N-DV-EN Digital Panel Meters with Diverse I/O
The MT4N-DV-EN digital panel meter measures DC voltage using a 4-digit 7-segment LCD with -1999 to 9999 display range. Manufactured by Autonics, this Autonics Digital Panel Meters with Diverse I/O model from the MT4N Series features 9 mm character height, front IP54 protection, DC voltage measurement, and optional power supply and output configurations for industrial automation panels.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MT4N-DV-EN |
Autonics MT4N-DV-EN Digital Panel Meters with Diverse I/O – Technical Specifications
| Specification | Value |
|---|---|
| Display method | 4-digit 7-segment LCD |
| Character height | 9mm |
| Max. display Range | -1999 to 9999 |
| Measurement | DC voltage |
| Input specification | 0-50V, 0-10V, 0-5V, 0-1V, 0-250mV, 0-50mV |
| Power supply | 12-24VDC @(=), 12-24VAC~ |
| Output_Main Output(Comparative Value) | Indicator |
| Display accuracy | • 23℃±5℃ - ± 0.1 % F.S. rdg ± 2 digit± 0.3 % F.S. rdg ± 3 digit max. only for 5A terminal.• -10℃ to 50℃ -± 0.5 % F.S. rdg ± 3 digit |
| A/D conversion method | ΣΔ (Sigma Delta) ADC |
| Sampling cycle | 50ms |
| Environment_Ambient temperature | -10 to 50℃, storage: -20 to 60℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Insulation type | Double insulation or reinforced insulation(mark: @(INS), dielectric strength between the measuring input part and the power part: 1kV) |
| Protection structure | IP54 (front part, IEC standard) |
| Unit weight (packaged weight) | ≈ 64 g (≈ 127 g) |
The Autonics MT4N-DV-EN Digital Panel Meters with Diverse I/O are designed for precise DC voltage indication in industrial automation environments. This Autonics panel meter offers a 4-digit LCD display, supports a -1999 to 9999 measurement range, and provides clear readability through a 9 mm character height. It belongs to the MT4N Series and is widely used in control panels across automation systems.
In applications such as conveyors, packaging machines, assembly lines, and electrical control cabinets, the MT4N-DV-EN supports continuous voltage monitoring. The DC voltage measurement function helps operators maintain stable power conditions, while the LCD interface allows fast visual checks. The front IP54 protection supports reliable operation in industrial environments exposed to dust.
The MT4N-DV-EN Autonics Digital Panel Meters with Diverse I/O reflect Autonics consistency in panel instrumentation. With defined measurement range, clear display format, and protective front design, this MT4N Series model suits long-term industrial automation use in India. Autonics digital panel meters are commonly selected where dependable voltage indication and standardized panel integration are required.
