Autonics MT4N-DV-E4 Digital Panel Meters with Diverse I/O
The MT4N-DV-E4 digital panel meter measures DC voltage using a 4-digit 7-segment LCD with -1999 to 9999 range display. Manufactured by Autonics, this Autonics Digital Panel Meters with Diverse I/O model from the MT4N Series includes 9 mm character height, front IP54 protection, DC voltage measurement, and optional power supply and output configurations for industrial panels.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | MT4N-DV-E4 |
Autonics MT4N-DV-E4 Digital Panel Meters with Diverse I/O – Technical Specifications
| Specification | Value |
|---|---|
| Display method | 4-digit 7-segment LCD |
| Character height | 9mm |
| Max. display Range | -1999 to 9999 |
| Measurement | DC voltage |
| Input specification | 0-50V, 0-10V, 0-5V, 0-1V, 0-250mV, 0-50mV |
| Power supply | 12-24VDC @(=), 12-24VAC~ |
| Output_Main Output(Comparative Value) | Relay (OUT1) |
| Output_Sub Output(Display Value) | RS485 communication |
| Display accuracy | • 23℃±5℃ - ± 0.1 % F.S. rdg ± 2 digit± 0.3 % F.S. rdg ± 3 digit max. only for 5A terminal.• -10℃ to 50℃ -± 0.5 % F.S. rdg ± 3 digit |
| A/D conversion method | ΣΔ (Sigma Delta) ADC |
| Sampling cycle | 50ms |
| Hold function | Includes (external hold function) |
| Environment_Ambient temperature | -10 to 50℃, storage: -20 to 60℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Insulation type | Double insulation or reinforced insulation(mark: @(INS), dielectric strength between the measuring input part and the power part: 1kV) |
| Protection structure | IP54 (front part, IEC standard) |
| Unit weight (packaged weight) | ≈ 64 g (≈ 127 g) |
The Autonics MT4N-DV-E4 Digital Panel Meters with Diverse I/O are designed for DC voltage indication in industrial automation systems. This Autonics panel meter provides a 4-digit LCD display, supports a -1999 to 9999 display range, and ensures readability with a 9 mm character height. As part of the MT4N Series, the MT4N-DV-E4 is commonly installed in electrical control panels across industrial environments.
In applications such as conveyors, packaging machines, automation lines, and assembly systems, the MT4N-DV-E4 supports continuous voltage monitoring. The DC voltage measurement function allows operators to observe power conditions clearly, while the panel-mounted format supports stable integration. The front IP54 protection enables consistent operation in environments where dust exposure is present.
The MT4N-DV-E4 Autonics Digital Panel Meters with Diverse I/O reflect Autonics reliability in panel instrumentation. With defined measurement capability, clear display format, and protective front construction, this MT4N Series model is suitable for long-term industrial automation use in India. Autonics digital panel meters are widely used where dependable voltage indication and standardized control panel design are required.
