Autonics CT6Y-I2T Counter
The Autonics CT6Y-I2T Counter offers 1, 30, 1k, 5k, 10k [cps] counting speed, 24VAC~ 50/60Hz, 24-48VDC power supply, Terminal block, Indicator control output. Manufactured by Autonics under the Autonics Counters category, this model belongs to the Autonics CT6Y Series.
| Brand | Autonics |
| Product Type | Counter |
| Model Number | CT6Y-I2T |
Autonics CT6Y-I2T Counter β Technical Specifications
| Specification | Value |
|---|---|
| Display method | 6-digit 7-segment LED |
| Max. Counting Speed | 1, 30, 1k, 5k, 10k [cps] |
| Counter_Counting range | -99999 to 999999 |
| Min. signal Width | 1ms/20ms |
| Power supply | 24VAC~ 50/60Hz, 24-48VDC |
| External Power Supply | Max. 12VDC @(=) Β±10%, 100mA |
| Operation method | Counter: Count up, Count down, Count up/downTimer: Count up, Count down |
| Terminal | Terminal block |
| Time operation | POWER ON STARTSIGNAL ON START |
| Signal Input Method | Voltage input(PNP), No-voltage input(NPN) |
| Setting range | 0.001 sec to 9.999 sec, 0.01 sec to 99.99 sec, 0.1 sec to 999.9 sec, 1 sec to 9999 sec, 1 sec to 99 min 59 sec, 0.1 min to 999.9 min, 1 min to 9999 min, 1 min to 99 hour 59 min, 1 hour to 9999 hour |
| Control output_Type | Indicator |
| Counter_Scale | Decimal point up to fifth digit |
| Counter_Min. input signal width | RESET: Selectable 1ms/20ms |
| Timer_Min. input signal width | INA, INH, RESET: Selectable 1ms/20ms |
| Communication output | RS485 |
| Memory Protection | Approx. 10 years |
| Environment_Ambient temperature | -10 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP65(front panel) |
| Weight | Approx. 228g (approx. 140g) |
Talk to Our Engineer for Programmable Digital Counter/Timers CT6Y-I2T with exclusive offers. Core System Specifications of CT6Y-I2T are counting the speed of 1, 30, 1k, 5k, 10k [cps], ensuring accurate data processing. With a minimum signal width of 1ms/20ms for counting value signals, they provide dependable performance in high-speed operations. Operating on a 24VAC~ 50/60Hz, 24-48VDC power supply, the sensors feature memory protection with a non-volatile semiconductor memory type, offering a retention period of approximately Approx. 10 years. Built to withstand challenging environments, they operate efficiently in a wide ambient temperature range -10 to 55β, storage: -25 to 65β and come with a robust protection structure IP65(front panel) to ensure durability. Compact and lightweight Approx. 228g (approx. 140g), these sensors are easy to install and integrate into existing systems. Don't Miss Out on a Quote for your requirement of Programmable Digital Counter/Timers. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
