Autonics CT6Y-1P2 Programmable Digital Counter/Timers
The CT6Y-1P2 Autonics Programmable Digital Counter/Timers support 10k cps counting speed, 6-digit LED display, and 24VAC/DC operation reliably. The CT6Y-1P2 belongs to Autonics industrial automation products and the Autonics Counter category. This model is part of the CT6Y Series and supports count up/down operation, 1-stage preset relay output, -99999 to 999999 counting range, and terminal block wiring connections.
| Brand | Autonics |
| Product Type | Counter |
| Model Number | CT6Y-1P2 |
Autonics CT6Y-1P2 Programmable Digital Counter/Timers – Technical Specifications
| Specification | Value |
|---|---|
| Display method | 6-digit 7-segment LED |
| Max. Counting Speed | 1, 30, 1k, 5k, 10k [cps] |
| Counter_Counting range | -99999 to 999999 |
| Min. signal Width | 1ms/20ms |
| Power supply | 24VAC~ 50/60Hz, 24-48VDC |
| External Power Supply | Max. 12VDC @(=) ±10%, 100mA |
| Operation method | Counter: Count up, Count down, Count up/downTimer: Count up, Count down |
| Terminal | Terminal block |
| Output Operation | SIGNAL ON DELAY, POWER ON DELAY, FLICKER, INTERVAL, SIGNAL OFF DELAY, ON-OFF DELAY, INTEGRATION TIME |
| Time operation | POWER ON STARTSIGNAL ON START |
| Signal Input Method | Voltage input(PNP), No-voltage input(NPN) |
| Setting range | 0.001 sec to 9.999 sec, 0.01 sec to 99.99 sec, 0.1 sec to 999.9 sec, 1 sec to 9999 sec, 1 sec to 99 min 59 sec, 0.1 min to 999.9 min, 1 min to 9999 min, 1 min to 99 hour 59 min, 1 hour to 9999 hour |
| Control output_Type | 1-stage preset |
| Control output_Relay | SPDT (1c): 1 |
| Counter_Scale | Decimal point up to fifth digit |
| Control output_NPN open collector | 1 |
| Counter_Min. input signal width | RESET: Selectable 1ms/20ms |
| Timer_Min. input signal width | INA, INH, RESET: Selectable 1ms/20ms |
| Memory Protection | Approx. 10 years |
| Environment_Ambient temperature | -10 to 55℃, storage: -25 to 65℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP65(front panel) |
| Weight | Approx. 228g (approx. 140g) |
The CT6Y-1P2 Autonics Programmable Digital Counter/Timers are industrial counting and timing devices from the CT6Y Series used in automation control systems. The CT6Y-1P2 supports 1, 30, 1k, 5k, and 10k cps counting speeds with a 6-digit 7-segment LED display for machine monitoring and process counting operations. It operates using 24VAC 50/60Hz and 24-48VDC power supply while supporting count up, count down, and timer operation modes. The Autonics counter also includes decimal point scaling, programmable timing functions, and SPDT relay output configuration for industrial control panels.
The CT6Y-1P2 is used in conveyors, packaging equipment, assembly systems, material handling units, and automated production lines requiring stable counting and timing control. Industrial users apply this counter for repetitive timing cycles, production counting, process synchronization, and machine sequence monitoring. Its relay output configuration helps maintain dependable signal communication between sensors and automation devices. The programmable timing operations support signal ON delay, flicker operation, interval timing, and integration timing for industrial environments requiring accurate counting and timing management.
CT6Y-1P2 Autonics Programmable Digital Counter/Timers combine 10k cps counting capability, SPDT relay output configuration, and 24VAC/DC operation for industrial automation requirements. The CT6Y Series provides reliable counting and timing control with terminal block wiring for machine panels and control cabinets. Autonics products are widely used in industrial automation systems because of their stable electrical operation and compatibility with factory equipment. The CT6Y-1P2 is suitable for engineers and panel builders requiring dependable counting, timer control, and relay output management in manufacturing applications.
