In most procurement cycles, BFX-D1-P is considered with Autonics Proximity Sensor, Autonics Digital Counter and Autonics Fiber Optic Sensors, giving decision-makers confidence that theyβve chosen the most dependable component.
Autonics BFX-D1-P Fiber Optic Sensor
The Autonics BFX-D1-P Fiber Optic Sensor offers Red LED(660nm) light source, 50γ², 150γ², 500γ², 4ms, 10ms response time, 12-24VDC power supply, Light ON/Dark ON(set by parameter) operation mode, PNP open collector control output. Manufactured by Autonics under the Autonics Fiber Optic Sensor category, this model belongs to the Autonics BFX Series.
| Brand | Autonics |
| Product Type | LCD Display Digital Fiber Optic Amplifiers |
| Model Number | BFX-D1-P |
Autonics BFX-D1-P Fiber Optic Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Dual display |
| Display method | 4-digit 7-segment LCD |
| Light source | Red LED(660nm) |
| Response time | 50γ², 150γ², 500γ², 4ms, 10ms |
| Power supply | 12-24VDC |
| Current consumption | Max. 50mA |
| Operation mode | Light ON/Dark ON(set by parameter) |
| Control output | PNP open collector |
| Timer function | OFF, OFF Delay, ON Delay, One-shot(1 to 5000ms) |
| Sensitivity adjustment | Manual Teaching(auto-tuning, 1-point, 2-point, positioning) |
| Protection structure | IP40 |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -10 to 50β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | Case: polyketon, cover: polycarbonates |
| Accessories | Connector type wire (Γ4mm, 4-wire, 2m / AWG22, core diameter: 0.08mm, number of cores: 60, insulator diameter: Γ1.25mm) |
| Weight | Approx. 115g(approx. 16g) |
The Autonics BFX-D1-P Fiber Optic Sensor is designed with dual 4-digit LCD displays for real-time monitoring of received light levels and output states. It uses a red LED light source (660 nm) to deliver stable detection across diverse applications, while response times as fast as 50γ² make it suitable for high-speed automation tasks. With a reliable 12β24 VDC power supply and maximum current consumption of 50 mA, this BFX Series Amplifier balances efficiency and performance. Engineers benefit from flexible Light ON/Dark ON modes, PNP open collector outputs, and advanced teaching options including auto-tuning, 1-point, 2-point, and positioning adjustments for precise calibration. Timer functions such as OFF delay, ON delay, and one-shot (1β5000 ms) enhance flexibility by reducing false triggers in demanding environments.
Built with a rugged polyketon case and polycarbonate cover, the BFX-D1-P maintains durability under industrial conditions with IP40 protection. It operates within -10β to +50β and withstands ambient light interference up to 11,000 lx, ensuring stable performance in factories. Maintenance engineers value its compact design, visible display, and quick parameter settings, which minimize downtime and improve usability. For wholesalers, dealers, and distributors, this model is a dependable option to support varied automation projects across sectors like automotive, packaging, food processing, and electronics manufacturing.
The Autonics BFX Series, including the BFX-D1-P, is trusted for its balance of precision, speed, and adaptability. Often searched as BFX Series Amplifier, BFX Series Price, Autonics BFX Series, or simply BFX, this sensor delivers consistent performance and proven results. Industrial buyers recognize it as a reliable choice for enhancing automation efficiency and ensuring long-term operation in critical detection applications.
