Autonics ABS-HC32PA-PN I/O Terminal Block
The Autonics ABS-HC32PA-PN I/O Terminal Blocks offers β€ 24 VDC voltage, Screw terminal type, 7.62 mm Terminal pitch, Power indicator: red, operating indicator: blue indicator. Manufactured by Autonics under the Autonics I/O Terminal Blocks category, this model belongs to the Autonics ASS Series.
| Brand | Autonics |
| Product Type | I/O Terminal Blocks |
| Model Number | ABS-HC32PA-PN |
Autonics ABS-HC32PA-PN I/O Terminal Block β Technical Specifications
| Specification | Value |
|---|---|
| Rated voltage | β€ 24 VDC |
| Current consumption | β€ 7.4 mA or β€ 10.1 mA |
| Number of connector pins | 40 |
| Terminal type | Screw |
| Terminal pitch | 7.62 mm |
| Indicator | Power indicator: red, operating indicator: blue |
| Applicable cable_Solid wire | Γ 0.3 to Γ 1.2 mm |
| Applicable cable_Stranded wire | AWG 22-16 (0.30 to 1.25 mmΒ²) |
| Applied relay | APAN3124 [MATSUSHITA(Panasonic)] |
| Number of relay points | 32 |
| Insulation resistance | β₯1,000Mβ¦ (at 500VDC megger) |
| Dielectric strength_Between coil-contacts | 3,000VAC 50/60Hz for 1 minute |
| Dielectric strength_Between same contacts | 1,000VAC 50/60Hz for 1 minute |
| Environment_Ambient temperature | -15 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | CASE: MPPO, BASE: PA66 (G25 %), COVER: PC, terminal pin: brass, Ni-plating |
| Weight | β 345 g (β 438 g) |
Obtain a Quote for Autonics Relay Terminal Blocks ABS-HC32PA-PN at economical prices. Specifications Overview for ABS-HC32PA-PN reveals β€ 24 VDC rated voltage, ensuring stable and efficient operation. The current consumption is β€ 7.4 mA or β€ 10.1 mA, optimizing energy efficiency. It features a Screw type terminal with an 7.62 mm terminal pitch, providing secure and reliable connections.
With β₯1,000Mβ¦ (at 500VDC megger) insulation resistance and dielectric strength of 3,000VAC 50/60Hz for 1 minute between coil-contacts and 1,000VAC 50/60Hz for 1 minute between the same contacts, this relay guarantees high electrical safety. It operates within an ambient temperature range of -15 to 55β, storage: -25 to 65β and humidity levels of 35 to 85% RH, storage: 35 to 85% RH, ensuring durability in industrial environments.
Constructed with CASE: MPPO, BASE: PA66 (G25 %), COVER: PC, terminal pin: brass, Ni-plating brass terminal pins, it is designed for longevity. With an approximate weight of β 345 g (β 438 g), it offers a robust yet lightweight design. Take the First Step with a Quote for your requirement of Relay Terminal Blocks. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
