Wenglor YW24NA3 Photoelectric Sensor
The Wenglor YW24NA3 Photoelectric Sensor offers 150 mm range, 10 ... 30 V DC supply voltage, 1,300 Hz, IP67, NPN NC, NPN NO output. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor PK Series.
| Brand | Wenglor |
| Product Type | Photoelectric Sensor |
| Model Number | YW24NA3 |
Wenglor YW24NA3 Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Range | 150 mm |
| Setting Range | 35 ... 150 mm |
| Switching Hysteresis | < 5 % |
| Light Source | Laser (red) |
| Max. Ambient Light | 10,000 Lux |
| Supply voltage | 10 ... 30 V DC |
| Current Consumption (Ub = 24 V) | < 25 mA |
| Switching Frequency | 1,300 Hz |
| Response Time | 385 µs |
| Temperature Range | -25 ... 60 °C |
| Switching Output Voltage Drop | < 2.5 V |
| Switching Output/Switching Current | 100 mA |
| Interface | - |
| Setting Method | Potentiometer |
| Housing Material | Stainless steel, V2A (1.4305 / 303) Plastic, PBT |
| Connection | M12 × 1; 4-pin |
| Output | NPN NC, NPN NO |
| Circuit | NC NC+NO NO |
| Optic Cover | - |
| Degree of Protection | IP67 |
| Weight | 40 g |
Give Us a Call for Wenglor 150 mm Reflex Sensor YW24NA3 at affordable rates. Specifications Overview for 10 includes range of 150 mm with a switching hysteresis of < 5 %. It uses a Laser (red) source and can handle a maximum ambient light of 10,000 Lux. The supply voltage ranges from 10 ... 30 V DC, with IO-Link operating at . The current consumption at < 25 mA
. It has a switching frequency of 1,300 Hz and in interference-free mode, with response times of 385 µs and , respectively. The sensor operates within a temperature range of -25 ... 60 °C. The switching output voltage drop is < 2.5 V, and the switching current is 100 mA. It features an -. interface and a Potentiometer setting method. The housing is made of Stainless steel, V2A (1.4305 / 303)
Plastic, PBT, with an M12 × 1; 4-pin connection. The output includes NPN NC, NPN NO circuits with various configurations, and the optic cover is made of -. The sensor is rated IP67.Unlock Exclusive Pricing with a Quote for your requirement of Wenglor 150 mm Reflex Sensor. We're committed to offering more favorable pricing and more responsive support than other Distributors.
