Home Wenglor Photoelectric Sensors Retro-Reflex Sensors XD100PCV3 Wenglor XD100PCV3 Photoelectric Sensor The Wenglor XD100PCV3 Photoelectric Sensor offers 14,000 mm range, 10 ... 30 V DC supply voltage, 3 kHz switching frequency, IP67 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Retro Series .
Brand Wenglor Product Type Photoelectric Sensor Model Number XD100PCV3
Wenglor XD100PCV3 Photoelectric Sensor – Technical Specifications Specification Value Range 14,000 mm Reference Reflector/Reflector Foil RQ100BA Smallest Recognizable Part 100 µm Switching Hysteresis < 15 % Light Source Laser (red) Polarization Filter yes Service Life (T = +25 °C) 100,000 h Max. Ambient Light 10,000 Lux Light Spot Diameter see Table 1 Two-Lens Optic yes Supply Voltage 10 ... 30 V DC Current Consumption (Ub = 24 V) < 30 mA Switching Frequency 3 kHz Response Time 167 µs Temperature Drift < 10 % Temperature Range -25 ... 60 °C Switching Output Voltage Drop < 2.5 V Short Circuit Protection yes Reverse Polarity Protection yes Overload Protection yes Protection Class III Setting Method Potentiometer Housing Material Stainless steel, V2A (1.4305 / 303) Degree of Protection IP67 Connection M12 × 1; 4-pin Weight 35 g MTTFd (EN ISO 13849-1) 2,153.46 a Circuit NC
NC/NO
NO Wavelength 655 nm
