Home Wenglor Fiber-Optic Cable Amplifiers Fiber-Optic Cable Amplifiers Series UF66PA3 Wenglor UF66PA3 Photoelectric Sensor The Wenglor UF66PA3 Photoelectric Sensor offers 10 ... 30 V DC supply voltage, 200 Hz switching frequency, -25 ... 60 °C temperature range, IP65 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor P1X Series .
Brand Wenglor Product Type Fiber-Optic Cable Amplifiers Model Number UF66PA3
Wenglor UF66PA3 Photoelectric Sensor – Technical Specifications Specification Value Switching Hysteresis < 15 % Light Source Infrared Light Service Life (T = +25 °C) 100,000 h Max. Ambient Light 10,000 Lux Supply Voltage 10 ... 30 V DC Current Consumption (Ub = 24 V) < 40 mA Switching Frequency 200 Hz Response Time 2,500 µs Temperature Drift < 10 % Temperature Range -25 ... 60 °C Switching Output Voltage Drop < 2.5 V Switching Output/Switching Current 200 mA Short Circuit Protection yes Reverse Polarity Protection yes Overload Protection yes Protection Class III Setting Method Potentiometer Housing Material Brass, nickel-plated Degree of Protection IP65 Connection M12 × 1; 4-pin Weight 127 g PNP NC, PNP NO yes Circuit NC, NC+NO, NO Range 1,000 mm Opening Angle 12 ° Residual Current Switching Output < 50 µA Optic Cover Plastic, PC Full Encapsulation yes
