Wenglor TC66PA3 Photoelectric Sensor

Name: Wenglor TC66PA3
Brand: Wenglor
SKU: TC66PA3
Rating: 4.9 (4 reviews)

The Wenglor TC66PA3 Photoelectric Sensor offers 1,000 mm range, 10 ... 30 V DC supply voltage, 1 kHz switching frequency, IP67 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Reflex Series.

Datasheet

Brand	Wenglor
Product Type	Photoelectric Sensor
Model Number	TC66PA3

Wenglor TC66PA3 Photoelectric Sensor – Technical Specifications

Specification	Value
Range	1,000 mm
Switching Hysteresis	< 15 %
Light Source	Infrared Light
Supply Voltage	10 ... 30 V DC
Current Consumption (Ub = 24 V)	< 40 mA
Switching Frequency	1 kHz
Response Time	500 µs
Temperature Drift	< 10 %
Temperature Range	-25 ... 60 °C
Switching Output Voltage Drop	< 2.5 V
Residual Current Switching Output	< 50 µA
Setting Method	Potentiometer
Housing Material	Stainless steel, V2A (1.4305 / 303)
Degree of Protection	IP67
Connection	M12 × 1; 4-pin
Weight	43 g
Circuit	NC NC+NO NO
Opening Angle	12 °
