Wenglor RO88PD3 Photoelectric Sensor
The Wenglor RO88PD3 Photoelectric Sensor offers 2,500 mm range, 10 ... 30 V DC supply voltage, 500 Hz switching frequency, IP65 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Retro Series.
| Brand | Wenglor |
| Product Type | Photoelectric Sensor |
| Model Number | RO88PD3 |
Wenglor RO88PD3 Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Range | 2,500 mm |
| Reference Reflector/Reflector Foil | RQ100BA |
| Switching Hysteresis | < 15 % |
| Light Source | Red Light |
| Polarization Filter | yes |
| Service Life (T = +25 °C) | 100,000 h |
| Max. Ambient Light | 10,000 Lux |
| Two-Lens Optic | yes |
| Supply Voltage | 10 ... 30 V DC |
| Current Consumption (Ub = 24 V) | < 40 mA |
| Switching Frequency | 500 Hz |
| Response Time | 1 ms |
| Temperature Drift | < 10 % |
| Temperature Range | -10 ... 60 °C |
| Switching Output Voltage Drop | < 2.5 V |
| Residual Current Switching Output | < 50 µA |
| Short Circuit Protection | yes |
| Reverse Polarity Protection | yes |
| Overload Protection | yes |
| Protection Class | III |
| Setting Method | Potentiometer |
| Housing Material | Brass, nickel-plated |
| Degree of Protection | IP65 |
| Connection | M12 × 1; 4-pin |
| Weight | 16 g |
