Home Wenglor Photoelectric Sensors Laser Distance Sensors P2PY101 Wenglor P2PY101 Photoelectric Sensor The Wenglor P2PY101 Photoelectric Sensor offers 0 ... 10,000 mm working range, 18 ... 30 V DC supply voltage, IP68, IP69K degree of Protection , M12 × 1; 5-pin connection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor laser Series .
Brand Wenglor Product Type Photoelectric Sensor Model Number P2PY101
Wenglor P2PY101 Photoelectric Sensor – Technical Specifications Specification Value Working Range 0 ... 10,000 mm Setting Range 50 ... 10,000 mm Switching Hysteresis < 15 mm Light Source Laser (red) Wavelength 660 nm Service Life (T = +25 °C) 100,000 h Laser Class (EN 60825-1) 1 Beam Divergence < 2 mrad Reflector required no Supply Voltage 18 ... 30 V DC Current Consumption (Ub = 24 V) < 35 mA Switching Frequency 50 Hz* Response Time 15 ms * Temperature Range -40 ... 55 °C Number of Switching Outputs 2 Switching Output Voltage Drop < 2.5 V Housing Material Stainless steel, V4A (1.4404 / 316L) Optic Cover Plastic, PMMA Degree of Protection IP68, IP69K Connection M12 × 1; 5-pin Circuit NC
NC/NO
NO Temperature Drift < 0.4 mm/K Switching Output/Switching Current 100 mA Output Error Output
Push-pull
NPN
Warning output Weight 182 g
