Wenglor P2KY012 Photoelectric Sensor
The Wenglor P2KY012 Photoelectric Sensor offers 0 ... 1,000 mm working range, 10 ... 30 V DC supply voltage, IP68, IP69K degree of Protection , M8 ร 1; 4-pin connection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor laser Series.
| Brand | Wenglor |
| Product Type | Photoelectric Sensor |
| Model Number | P2KY012 |
Wenglor P2KY012 Photoelectric Sensor โ Technical Specifications
| Specification | Value |
|---|---|
| Working Range | 0 ... 1,000 mm |
| Setting Range | 100 ... 1,000 mm |
| Switching Hysteresis | < 20 mm |
| Light Source | Laser (red) |
| Wavelength | 680 nm |
| Service Life (T = +25 ยฐC) | 100,000 h |
| Laser Class (EN 60825-1) | 1 |
| Beam Divergence | < 16 mrad |
| Reflector required | no |
| Supply Voltage | 10 ... 30 V DC |
| Current Consumption (Ub = 24 V) | < 30 mA |
| Switching Frequency | 500 Hz |
| Response Time | 1 ms |
| Temperature Range | -40 ... 50 ยฐC |
| Number of Switching Outputs | 2 |
| Switching Output Voltage Drop | < 2.5 V |
| Housing Material | Stainless steel, V4A (1.4404 / 316L) |
| Optic Cover | Plastic, PMMA |
| Degree of Protection | IP68, IP69K |
| Connection | M8 ร 1; 4-pin |
| Switching Output/Switching Current | 100 mA |
| Weight | 56 g |
