Home Wenglor Photoelectric Sensors Retro-Reflex Sensors P2KK002 Wenglor P2KK002 Photoelectric Sensor The Wenglor P2KK002 Photoelectric Sensor offers 2,000 mm range, 10 ... 30 V DC supply voltage, 1,000 Hz switching frequency, IP68, IP69K degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Retro Series .
Brand Wenglor Product Type Photoelectric Sensor Model Number P2KK002
Wenglor P2KK002 Photoelectric Sensor – Technical Specifications Specification Value Range 2,000 mm Reference Reflector/Reflector Foil RQ100BA Clear Glass Recognition yes Smallest Recognizable Part see Table 2 Switching Hysteresis < 5 % Light Source Red Light Polarization Filter yes Service Life (T = +25 °C) 100,000 h Max. Ambient Light 10,000 Lux Light Spot Diameter see Table 1 Single-Lens Optic yes Supply Voltage 10 ... 30 V DC Supply Voltage with IO-Link 18 ... 30 V DC Current Consumption (Ub = 24 V) < 20 mA Switching Frequency 1,000 Hz Switching frequency (speed mode) 2,000 Hz Response Time 0.5 ms Response time (speed mode) 0.25 ms Temperature Drift < 5 % Temperature Range -40 ... 60 °C Switching Output Voltage Drop < 2 V Switching Output/Switching Current 100 mA Residual Current Switching Output < 50 µA Short Circuit Protection yes Reverse Polarity Protection yes Overload Protection yes Lockable yes Interface IO-Link V1.1 Protection Class III Setting Method Teach-In Housing Material Stainless steel, V4A (1.4404 / 316L) Degree of Protection IP68, IP69K Connection M8 × 1; 4-pin Optic Cover Plastic, PMMA Weight 42 g MTTFd (EN ISO 13849-1) 2,175.32 a IO-Link yes PNP NC, PNP NO yes Output NPN
PNP
Push-pull Circuit NC
NO
NC/NO Other parameters Off-delay
On-delay
Emitted light
Mode of operation
Hysteresis
Dynamic readjustment RQ100BA 0 ... 2 m RE18040BA 0 ... 1.1 m RQ84BA 0 ... 1.6 m RR84BA 0 ... 1.9 m RE9538BA 0 ... 0.7 m RE6151BM 0 ... 1.5 m RR50_A 0 ... 1.05 m RE6040BA 0 ... 1.2 m RE8222BA 0 ... 0.85 m RR34_M 0 ... 1 m RE3220BM 0 ... 0.7 m RE6210BM 0 ... 0.45 m RR25_M 0 ... 0.55 m RR25KP 0 ... 0.3 m RR21_M 0 ... 0.5 m Z90R004 0 ... 0.7 m Z90R005 0 ... 1 m ZRAE02B01 0 ... 0.7 m ZRME01B01 0 ... 0.25 m ZRME03B01 0 ... 0.9 m ZRMR02K01 0 ... 0.35 m ZRMS02_01 0 ... 0.45 m RF505 0 ... 0.4 m RF508 0 ... 0.4 m RF258 0 ... 0.4 m ZRDF03K01 0 ... 1.2 m ZRDF10K01 0 ... 1.3 m Z90R012 0 ... 0.53 m Z90R013 0.02 ... 1.21 m Z90R014 0 ... 0.97 m Z90R015 0 ... 0.6 m Teach Mode NT, MT Data Storage yes Z90R006 0 ... 1 m ZRAF08K01 0 ... 0.4 m
