Wenglor P1PY217 Photoelectric Sensor
The Wenglor P1PY217 Photoelectric Sensor offers 0 ... 5,000 mm working range, 18 ... 30 V DC supply voltage, IP67, IP68 degree of Protection , M12 × 1; 5-pin connection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor laser Series.
| Brand | Wenglor |
| Product Type | Photoelectric Sensor |
| Model Number | P1PY217 |
Wenglor P1PY217 Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Working Range | 0 ... 5,000 mm |
| Light Source | Laser (blue) |
| Wavelength | 445 nm |
| Service Life (T = +25 °C) | 100,000 h |
| Laser Class (EN 60825-1) | 2 |
| Reflector required | no |
| Supply Voltage | 18 ... 30 V DC |
| Current Consumption (Ub = 24 V) | < 60 mA |
| Temperature Range | -40 ... 50 °C |
| Housing Material | Plastic, ABS |
| Optic Cover | Plastic, PMMA |
| Degree of Protection | IP67, IP68 |
| Connection | M12 × 1; 5-pin |
| Temperature Drift | < 0.4 mm/K |
| Output | Error Output Warning output |
| Measuring Range | 50 ... 5,000 mm |
| Measuring Rate | 100 /s* |
| Weight | 45 g |
