Home Wenglor Photoelectric Sensors Retro-Reflex Sensors P1NK205 Wenglor P1NK205 Photoelectric Sensor The Wenglor P1NK205 Photoelectric Sensor offers 3,500 mm range, 15 ... 30 V DC supply voltage, 1,000 Hz switching frequency, IP67, IP68 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Retro Series .
Brand Wenglor Product Type Photoelectric Sensor Model Number P1NK205
Wenglor P1NK205 Photoelectric Sensor – Technical Specifications Specification Value Range 3,500 mm Reference Reflector/Reflector Foil RQ100BA Clear Glass Recognition yes Smallest Recognizable Part see Table 2 Switching Hysteresis < 5 % Light Source Red Light Polarization Filter yes Service Life (T = +25 °C) 100,000 h Max. Ambient Light 10,000 Lux Light Spot Diameter see Table 1 Single-Lens Optic yes Supply Voltage 15 ... 30 V DC Supply Voltage with IO-Link 18 ... 30 V DC Current Consumption (Ub = 24 V) < 20 mA Switching Frequency 1,000 Hz Switching frequency (speed mode) 2,000 Hz Response Time 0.5 ms Response time (speed mode) 0.25 ms Temperature Drift < 3 % Temperature Range -40 ... 60 °C Switching Output Voltage Drop < 2 V Switching Output/Switching Current 100 mA Residual Current Switching Output < 50 µA Short Circuit Protection yes Reverse Polarity Protection yes Overload Protection yes Lockable yes Interface IO-Link V1.1 Protection Class III Setting Method Teach-in/NFC Housing Material Plastic, ABS/PC Degree of Protection IP67, IP68 Connection M12 × 1; 4-pin Optic Cover Plastic, PMMA Weight 27 g MTTFd (EN ISO 13849-1) 1,764.37 a IO-Link yes Output Push-pull
PNP
Contamination Output Circuit NC
NO
NC/NO Other parameters Off-delay
On-delay
Mode of operation
Hysteresis
Switching point
Emitted light
Dynamic readjustment RQ100BA 0 ... 3.5 m RE18040BA 0 ... 2.5 m RQ84BA 0 ... 3 m RR84BA 0 ... 3.5 RE9538BA 0 ... 1.4 m RE6151BM 0 ... 2.8 m RR50_A 0 ... 2.5 m RE6040BA 0 ... 2.8 m RE8222BA 0 ... 1.6 m RR34_M 0 ... 1.8 m RE3220BM 0 ... 1.1 m RE6210BM 0 ... 0.8 m RR25_M 0 ... 1 m RR25KP 0 ... 0.5 m RR21_M 0 ... 0.7 m Z90R004 0 ... 1.3 m Z90R005 0 ... 1.5 m ZRAE02B01 0 ... 1.5 m ZRME01B01 0 ... 0.35 m ZRME03B01 0 ... 1.5 m ZRMR02K01 0 ... 1.5 m ZRMS02_01 0 ... 0.7 m RF508 0 ... 0.7 m RF258 0 ... 0.7 m ZRDF10K01 0 ... 2.4 m Teach Mode NT, MT Data Storage yes
