Wenglor P1KY103 Photoelectric Sensor
The Wenglor P1KY103 Photoelectric Sensor offers 0 ... 1,500 mm working range, 10 ... 30 V DC supply voltage, IP67, IP68 degree of Protection , M8 × 1; 4-pin connection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor laser Series.
| Brand | Wenglor |
| Product Type | Photoelectric Sensor |
| Model Number | P1KY103 |
Wenglor P1KY103 Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Working Range | 0 ... 1,500 mm |
| Setting Range | 50 ... 1,500 mm |
| Switching Hysteresis | < 30 mm |
| Light Source | Laser (infrared) |
| Wavelength | 940 nm |
| Service Life (T = +25 °C) | 100,000 h |
| Laser Class (EN 60825-1) | 1 |
| Reflector required | no |
| Supply Voltage | 10 ... 30 V DC |
| Current Consumption (Ub = 24 V) | < 15 mA |
| Switching Frequency | 10 Hz |
| Response Time | < 36 ms |
| Temperature Range | -30 ... 50 °C |
| Number of Switching Outputs | 2 |
| Switching Output Voltage Drop | < 2.5 V |
| Housing Material | Plastic, ABS/PC Plastic, PC |
| Optic Cover | Plastic, PMMA |
| Degree of Protection | IP67, IP68 |
| Connection | M8 × 1; 4-pin |
| Circuit | NC NO |
| Temperature Drift | < 2.5 % |
| Switching Output/Switching Current | 100 mA |
| Weight | 28 g |
