Home Wenglor Photoelectric Sensors Reflex Sensor P1KT004 Wenglor P1KT004 Photoelectric Sensor The Wenglor P1KT004 Photoelectric Sensor offers 100 mm range, 10 ... 30 V DC supply voltage, 500 Hz switching frequency, IP67, IP68 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Reflex Series .
Brand Wenglor Product Type Photoelectric Sensor Model Number P1KT004
Wenglor P1KT004 Photoelectric Sensor โ Technical Specifications Specification Value Range 100 mm Switching Hysteresis < 10 % Light Source Red Light (Line) Supply Voltage 10 ... 30 V DC Supply Voltage with IO-Link 18 ... 30 V DC Current Consumption (Ub = 24 V) < 20 mA Switching Frequency 500 Hz Switching frequency (speed mode) 750 Hz Response Time 1 ms Response time (speed mode) 0.67 ms Temperature Drift < 5 % Temperature Range -40 ... 60 ยฐC Switching Output Voltage Drop < 2 V Switching Output/Switching Current 100 mA Residual Current Switching Output < 50 ยตA Setting Method Potentiometer Housing Material Plastic, ABS/PC Degree of Protection IP67, IP68 Connection M8 ร 1; 4-pin Optic Cover Plastic, PMMA Weight 6 g Output Push-pull
NPN
PNP Circuit NC
NC/NO
NO
