Home Wenglor Photoelectric Sensors Retro-Reflex Sensors P1KL008 Wenglor P1KL008 Photoelectric Sensor The Wenglor P1KL008 Photoelectric Sensor offers 12,000 mm range, 10 ... 30 V DC supply voltage, 2,000 Hz switching frequency, IP67, IP68 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Retro Series .
Brand Wenglor Product Type Photoelectric Sensor Model Number P1KL008
Wenglor P1KL008 Photoelectric Sensor – Technical Specifications Specification Value Range 12,000 mm Reference Reflector/Reflector Foil RE6151BM Smallest Recognizable Part see Table 2 Switching Hysteresis < 15 % Light Source Laser collimated (red) Polarization Filter yes Service Life (T = +25 °C) 100,000 h Max. Ambient Light 10,000 Lux Light Spot Diameter see Table 1 Two-Lens Optic yes Supply Voltage 10 ... 30 V DC Supply Voltage with IO-Link 18 ... 30 V DC Current Consumption (Ub = 24 V) < 15 mA Switching Frequency 2,000 Hz Switching frequency (speed mode) 4,000 Hz Response Time 0.25 ms Response time (speed mode) 0.125 ms Temperature Drift < 10 % Temperature Range -40 ... 60 °C Switching Output Voltage Drop < 2 V Switching Output/Switching Current 100 mA Residual Current Switching Output < 50 µA Short Circuit Protection yes Reverse Polarity Protection yes Overload Protection yes Lockable yes Interface IO-Link V1.1 Protection Class III Setting Method Potentiometer Housing Material Plastic, ABS/PC Degree of Protection IP67, IP68 Connection M8 × 1; 3-pin Optic Cover Plastic, PMMA Weight 6 g MTTFd (EN ISO 13849-1) 2,633.47 a IO-Link yes Output Push-pull, NPN, PNP Circuit NC
NO
NC/NO Wavelength 680 nm
