Wenglor P1KH006 Photoelectric Sensor
The Wenglor P1KH006 Photoelectric Sensor offers 120 mm range, 10 ... 30 V DC supply voltage, 1,000 Hz, IP67/IP68, Push-pull, NPN, PNP output. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor PK Series.
| Brand | Wenglor |
| Product Type | Photoelectric Sensor |
| Model Number | P1KH006 |
Wenglor P1KH006 Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Range | 120 mm |
| Setting Range | 30 ... 120 mm |
| Switching Hysteresis | < 10 % |
| Light Source | Laser (red) |
| Max. Ambient Light | 10,000 Lux |
| Supply voltage | 10 ... 30 V DC |
| Supply voltage with IO Link | 18 ... 30 V DC |
| Current Consumption (Ub = 24 V) | < 15 mA |
| Switching Frequency | 1,000 Hz |
| Switching Frequency (interference-free mode) | 500 Hz |
| Response time (interference-free mode) | 1 ms |
| Response Time | 0.5 ms |
| Temperature Range | 40 ... 60 °C |
| Switching Output Voltage Drop | < 2 V |
| Switching Output/Switching Current | 100 mA |
| Interface | IO-Link V1.1 |
| Setting Method | Potentiometer |
| Housing Material | Plastic, ABS/PC |
| Connection | M8 × 1; 4-pin |
| Output | Push-pull, NPN, PNP |
| Circuit | inactive Error output NC NC+NO NO |
| Optic Cover | Plastic, PMMA |
| Degree of Protection | IP67/IP68 |
| Weight | 6 g |
IndMALL Automation Dealing offers Wenglor 30VDC Reflex Photoelectric Sensor P1KH006 at unbeatable prices. The Main Technical Parameters of P1KH006 features range of 120 mm with a switching hysteresis of < 10 %
. It uses a Laser (red)
source and can handle a maximum ambient light of 10,000 Lux
. The supply voltage ranges from 10 ... 30 V DC, with IO-Link operating at 18 ... 30 V DC
. The current consumption at < 15 mA
. It has a switching frequency of 1,000 Hz and 500 Hz
in interference-free mode, with response times of 0.5 ms and 1 ms, respectively. The sensor operates within a temperature range of 40 ... 60 °C. The switching output voltage drop is < 2 V, and the switching current is 100 mA. It features an IO-Link V1.1. interface and a Potentiometer setting method. The housing is made of Plastic, ABS/PC, with an M8 × 1; 4-pin connection. The output includes Push-pull, NPN, PNP circuits with various configurations, and the optic cover is made of Plastic, PMMA
. The sensor is rated IP67/IP68. Take the First Step with a Quote for your requirement of Wenglor 30VDC Reflex Photoelectric Sensor. Choose us for unparalleled pricing and support over other Dealers & Distributors.
