OSEI501Z0103 - Wenglor Light Curtain

Name: Wenglor OSEI501Z0103
Brand: Wenglor
SKU: OSEI501Z0103
Rating: 5 (5 reviews)

The Wenglor OSEI501Z0103 Photoelectric Sensor offers 2,000 mm range, 50 mm measurement field height (MFH), Emitter sensor type, 18 ... 30 V DC supply voltage. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Light Curtain Series.

Datasheet

Brand	Wenglor
Product Type	Light Curtain
Model Number	OSEI501Z0103

Technical Specifications of OSEI501Z0103 Wenglor Light Curtain

Specification	Value
Range	2,000 mm
Measurement Field Height (MFH)	50 mm
Beam Distance	2 mm
Light Source	Infrared Light
Service Life (T = +25 °C)	100,000 h
Sensor Type	Emitter
Supply Voltage	18 ... 30 V DC
Current Consumption (Ub = 24 V)	< 60 mA
Temperature Drift	< 10 %
Temperature Range	-25 ... 60 °C
Reverse Polarity Protection	yes
Test input	yes
Protection Class	III
Housing Material	Aluminum, powder-coated Plastic, PA Plastic, PBT
Optic Cover	Plastic, PC
Degree of Protection	IP65
Connection	M12 × 1; 4-pin
Weight	279 g
MTTFd (EN ISO 13849-1)	1,330.08 a
