Home Wenglor Photoelectric Sensors Through-Beam Sensors LV250PCT Wenglor LV250PCT Photoelectric Sensor The Wenglor LV250PCT Photoelectric Sensor offers 15,000 mm range, Control unit sensor type, 18 ... 30 V supply voltage, IP20 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Through-Beam Series .
Brand Wenglor Product Type Through-Beam Sensors Model Number LV250PCT
Wenglor LV250PCT Photoelectric Sensor – Technical Specifications Specification Value Range 15,000 mm Sensor Type Control unit Supply Voltage 18 ... 30 V Current Consumption (Ub = 24 V) 120 mA Temperature Drift < 10 % Temperature Range -25 ... 60 °C Reverse Polarity Protection yes Protection Class III Housing Material Plastic Degree of Protection IP20 Weight 166 g Switching Frequency 250 Hz Response Time 4 ms Switching Output Voltage Drop < 2.5 V Switching Output/Switching Current 200 mA Short Circuit Protection yes Overload Protection yes Setting Method Teach-In On-/Off-Delay 50 ms Error Output/Switching Current 200 mA Teach Mode NT, MT cascadable yes Logic Output AND / OR External teach-in input yes DIN-Rail mounting 35 mm PNP NO/NC switchable yes
