Home Wenglor Photoelectric Sensors Retro-Reflex Sensors LB66PC7K Wenglor LB66PC7K Photoelectric Sensor The Wenglor LB66PC7K Photoelectric Sensor offers 1,300 mm range, 10 ... 30 V DC supply voltage, 1,800 Hz switching frequency, IP67 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Retro Series .
Brand Wenglor Product Type Photoelectric Sensor Model Number LB66PC7K
Wenglor LB66PC7K Photoelectric Sensor – Technical Specifications Specification Value Range 1,300 mm Reference Reflector/Reflector Foil RQ100BA Switching Hysteresis < 15 % Light Source Red Light Polarization Filter yes Service Life (T = +25 °C) 100,000 h Max. Ambient Light 10,000 Lux Two-Lens Optic yes Supply Voltage 10 ... 30 V DC Current Consumption (Ub = 24 V) < 20 mA Switching Frequency 1,800 Hz Response Time 270 µs Temperature Drift < 10 % Temperature Range -10 ... 60 °C Switching Output Voltage Drop < 2.5 V Residual Current Switching Output < 50 µA Short Circuit Protection yes Reverse Polarity Protection yes Overload Protection yes Protection Class III Housing Material Stainless steel, V2A (1.4305 / 303) Degree of Protection IP67 Connection M8 × 1; 4-pin Weight 12 g Circuit NC
NC/NO
NO
