Wenglor LB66PC7 Photoelectric Sensor
The Wenglor LB66PC7 Photoelectric Sensor offers 1,300 mm range, 10 ... 30 V DC supply voltage, 1,800 Hz switching frequency, IP67 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Retro Series.
| Brand | Wenglor |
| Product Type | Photoelectric Sensor |
| Model Number | LB66PC7 |
Wenglor LB66PC7 Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Range | 1,300 mm |
| Reference Reflector/Reflector Foil | RQ100BA |
| Switching Hysteresis | < 15 % |
| Light Source | Red Light |
| Polarization Filter | yes |
| Service Life (T = +25 °C) | 100,000 h |
| Max. Ambient Light | 10,000 Lux |
| Two-Lens Optic | yes |
| Supply Voltage | 10 ... 30 V DC |
| Current Consumption (Ub = 24 V) | < 20 mA |
| Switching Frequency | 1,800 Hz |
| Response Time | 270 µs |
| Temperature Drift | < 10 % |
| Temperature Range | -10 ... 60 °C |
| Switching Output Voltage Drop | < 2.5 V |
| Residual Current Switching Output | < 50 µA |
| Short Circuit Protection | yes |
| Reverse Polarity Protection | yes |
| Overload Protection | yes |
| Protection Class | III |
| Housing Material | Stainless steel, V2A (1.4305 / 303) |
| Degree of Protection | IP67 |
| Connection | M8 × 1; 4-pin |
| Weight | 6 g |
| Circuit | NC NC/NO NO |
