Home Wenglor Photoelectric Sensors Retro-Reflex Sensors L1FL66VD Wenglor L1FL66VD Photoelectric Sensor The Wenglor L1FL66VD Photoelectric Sensor offers 1,400 mm range, 10 ... 30 V DC supply voltage, 2 kHz switching frequency, IP67 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Retro Series .
Brand Wenglor Product Type Photoelectric Sensor Model Number L1FL66VD
Wenglor L1FL66VD Photoelectric Sensor – Technical Specifications Specification Value Range 1,400 mm Reference Reflector/Reflector Foil RQ100BA Switching Hysteresis < 15 % Light Source Red Light Polarization Filter yes Service Life (T = +25 °C) 100,000 h Max. Ambient Light 10,000 Lux Two-Lens Optic yes Supply Voltage 10 ... 30 V DC Current Consumption (Ub = 24 V) < 30 mA Switching Frequency 2 kHz Response Time 250 µs Temperature Drift < 10 % Temperature Range -10 ... 60 °C Switching Output Voltage Drop < 2.5 V Residual Current Switching Output < 50 µA Short Circuit Protection yes Reverse Polarity Protection yes Overload Protection yes Protection Class III Housing Material Plastic, ABS/GF Degree of Protection IP67 Connection Cable; 3-wire Weight 49 g
