Home Wenglor Inductive Sensor Inductive Series INTT313 Wenglor INTT313 Inductive Sensor The Wenglor INTT313 Inductive Sensor offers 40 mm switching distance, Non-flush mounting, 0...80 supply voltage, M12 × 1; 4-pin connection. Manufactured by Wenglor under the Wenglor Inductive Sensor category, this model belongs to the Wenglor Inductive Series .
Brand Wenglor Product Type Inductive Sensor Model Number INTT313
Wenglor INTT313 Inductive Sensor – Technical Specifications Specification Value Switching Distance 40 mm Standard Target 120 × 120 mm Correction Factors Stainless Steel V2A/CuZn/Al 1,10/0,65/0,58 Mounting Non-flush Mounting A/B/C/D in mm 60/120/80/20 Mounting B1 in mm 0...80 Switching Hysteresis < 10 % Supply Voltage 10 ... 30 V DC Supply Voltage with IO-Link 18 ... 30 V DC Current Consumption (Ub = 24 V) < 15 mA Switching Frequency 50 Hz Temperature Drift < 10 % Sensor head temperature range -10 ... 250 °C Temperature range of the plug 0 ... 70 °C Number of Switching Outputs 2 Switching Output Voltage Drop < 1 V Switching Output/Switching Current 100 mA Residual Current Switching Output < 100 µA Short Circuit Protection yes Reverse Polarity Protection yes Overload Protection yes Interface IO-Link V1.1 Protection Class III Service Life (T = +200 °C) 100,000 h Service Life (T = +250 °C) 60,000 h Sensing face Plastic, PEEK Sensor head material Stainless steel, V2A (1.4301 / 304) Analysis module material Brass, nickel-plated Degree of protection, sensor head IP65 Degree of protection of the plug IP65 Connection M12 × 1; 4-pin Cable Length (L) 30 m Cable Jacket Material Plastic, PFA Outer diameter cable 3.4 mm PWIS-free yes Weight 1,560 g MTTFd (EN ISO 13849-1) 3,706.54 a Error Indicator yes Programmable switching distance 30/35/40 mm Error Output yes PNP NC, PNP NO yes Output Error Output
Push-pull
NPN
PNP Circuit NC
NO
NC+NO
