Home Wenglor Inductive Sensor Inductive Series INTT111 Wenglor INTT111 Inductive Sensor The Wenglor INTT111 Inductive Sensor offers 40 mm switching distance, Non-flush mounting, M12 × 1; 4-pin connection. Manufactured by Wenglor under the Wenglor Inductive Sensor category, this model belongs to the Wenglor Inductive Series .
Brand Wenglor Product Type Inductive Sensor Model Number INTT111
Wenglor INTT111 Inductive Sensor – Technical Specifications Specification Value Switching Distance 40 mm Correction Factors Stainless Steel V2A/CuZn/Al 0,81/0,56/0,52 Mounting Non-flush Mounting A/B/C/D in mm 70/120/80/25 Switching Hysteresis < 10 % Supply Voltage 10 ... 30 V DC Current Consumption (Ub = 24 V) < 40 mA Switching Frequency 60 Hz Temperature Drift < 10 % Sensor head temperature range -10 ... 250 °C Number of Switching Outputs 2 Switching Output Voltage Drop < 2.5 V Switching Output/Switching Current 100 mA Residual Current Switching Output < 10 mA Short Circuit Protection yes Protection Class III Service Life (T = +200 °C) 100,000 h Service Life (T = +250 °C) 60,000 h Sensing face PTFE Sensor head material Aluminum, anodised Analysis module material Aluminum, powder-coated Degree of protection, sensor head IP60 Connection M12 × 1; 4-pin Cable Length (L) 20 m Cable Jacket Material Stainless steel, V2A (1.4301 / 304) Outer diameter cable 5.3 mm PWIS-free yes Weight 2,077 g MTTFd (EN ISO 13849-1) 1,155.13 a PNP NC, PNP NO yes Temperature Range, Plug on Sensor Head 0 ... 50 °C Analysis module temperature range 0 ... 50 °C Degree of protection, analysis module IP67 Maintenance output yes
